| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 2A5-979-2531 | Hose | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 20Y-979-3140 | • O-Ring | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01435-00630 | Bolt | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01435-00625 | Bolt | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 04434-51912 | Clip | 4 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01010-81225 | Bolt | 3 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01643-31232 | Washer | 3 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01010-81235 | Bolt | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01643-31232 | Washer | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 198-43-15310 | Collar | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 04434-51512 | Clip | 4 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01010-81225 | Bolt | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01643-31232 | Washer | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 20Y-03-11220 | Collar | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01010-81260 | Bolt | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01643-31232 | Washer | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 04434-52112 | Clip | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 195-979-3570 | Collar | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01010-81295 | Bolt | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01643-31232 | Washer | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 2A5-979-1470 | Clip | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 20Y-03-11220 | Collar | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01010-81260 | Bolt | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01643-31232 | Washer | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 2A5-979-1561 | Bracket | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01010-81225 | Bolt | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01643-31232 | Washer | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 20Y-810-1170 | Clip | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01010-81225 | Bolt | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 01643-31232 | Washer | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 6218-81-8480 | Band | 2 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | 08034-20519 | Band | 1 | SN: K77001- KIT-FLAG: _- SCC: SERIALNO: K77001- |
|||
| ? | (2A5-979-1891) | Hose Assembly (Cab,Floor, Air Conditioner Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
K1110-010065 | |||
| ? | (2A5-979-2540) | Hose (Cab,Floor, Air Conditioner Piping) | KIT-FLAG: _- SCC: SERIALNO: - |
K1110-010065 |
