| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6205-61-1301 | WATER PUMP ASSEMBLY | 1 | Field_1: WATER PUMP ASSEMBLY Field_2: 9999999- code: |
|||
| ? | • BODY | 1 | Field_1: BODY Field_2: 9999999- code: C1 |
||||
| ? | 6204-61-1630 | • IMPELLER | 1 | Field_1: IMPELLER Field_2: 9999999- code: |
|||
| ? | 6271-61-1520 | • SEAL, WATER | 1 | Field_1: SEAL, WATER Field_2: 9999999- code: |
|||
| ? | 6204-61-1650 | • SHAFT | 1 | Field_1: SHAFT Field_2: 9999999- code: |
|||
| ? | 6205-61-1210 | • BOSS | 1 | Field_1: BOSS Field_2: 9999999- code: |
|||
| ? | 6206-61-1121 | • COVER | 1 | Field_1: COVER Field_2: 9999999- code: |
|||
| ? | 6204-61-1660 | • GASKET | 1 | Field_1: GASKET Field_2: 9999999- code: |
|||
| ? | 01236-40816 | • SCREW | 5 | Field_1: SCREW Field_2: 9999999- code: |
|||
| ? | 6205-61-8680 | • TUBE | 1 | Field_1: TUBE Field_2: 9999999- code: |
|||
| ? | 6206-61-1731 | GASKET | 1 | Field_1: GASKET Field_2: 9999999- code: |
|||
| ? | 07000-03040 | O-RING | 1 | Field_1: O-RING Field_2: 9999999- code: |
|||
| ? | 01435-00855 | BOLT | 3 | Field_1: BOLT Field_2: 9999999- code: |
|||
| ? | 6205-61-8690 | HOSE | 1 | Field_1: HOSE Field_2: 9999999- code: |
