| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-3M-00034 | PUMP ASSEMBLY | 1 | Field_1: PUMP ASSEMBLY Field_2: DBBY0001- code: |
|||
| ? | 708-3M-01034 | PUMP ASSEMBLY | 1 | Field_1: PUMP ASSEMBLY Field_2: DBBY0001- code: |
|||
| ? | (708-2G-03480) | • COVER ASSEMBLY | 1 | Field_1: COVER ASSEMBLY Field_2: DBBY0001- code: C2 |
|||
| ? | (708-2G-14310) | • • SCREW | 1 | Field_1: SCREW Field_2: DBBY0001- code: C2 |
|||
| ? | (07000-B3038) | • • • O-RING | 1 | Field_1: O-RING Field_2: DBBY0001- code: C2 |
|||
| ? | (708-2G-15230) | • • • RING, BACK-UP | 1 | Field_1: RING, BACK-UP Field_2: DBBY0001- code: C2 |
|||
| ? | (708-2L-35290) | • • • NUT | 1 | Field_1: NUT Field_2: DBBY0001- code: C2 |
|||
| ? | (708-2G-14170) | • • • COVER | 1 | Field_1: COVER Field_2: DBBY0001- code: C2 |
|||
| ? | (07000-B2050) | • • • O-RING | 1 | Field_1: O-RING Field_2: DBBY0001- code: C2 |
|||
| ? | (708-2G-15310) | • • • RING, BACK-UP | 1 | Field_1: RING, BACK-UP Field_2: DBBY0001- code: C2 |
|||
| ? | (01252-61645) | • • BOLT, HEXAGON SOCKET HEAD | 4 | Field_1: BOLT, HEXAGON SOCKET HEAD Field_2: DBBY0001- code: C2 |
|||
| ? | (708-3M-11620) | • • IMPEIIER | 1 | Field_1: IMPEIIER Field_2: DBBY0001- code: C2 |
|||
| ? | (708-1H-32150) | • • NUT | 1 | Field_1: NUT Field_2: DBBY0001- code: C2 |
|||
| ? | (07000-A5185) | • • O-RING | 1 | Field_1: O-RING Field_2: DBBY0001- code: C2 |
|||
| ? | 708-3M-11720 | • • COVER | 1 | Field_1: COVER Field_2: DBBY0001- code: |
|||
| ? | 01010-81235 | • • BOLT | 4 | Field_1: BOLT Field_2: DBBY0001- code: |
|||
| ? | 08193-21012 | • • CLIP | 2 | Field_1: CLIP Field_2: DBBY0001- code: |
|||
| ? | 01010-81245 | • • BOLT | 2 | Field_1: BOLT Field_2: DBBY0001- code: |
|||
| ? | 01643-31232 | • • WASHER | Field_1: WASHER Field_2: code: |
||||
| ? | 198-43-15310 | • • BUSHING | Field_1: BUSHING Field_2: code: |
