| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-06-05906 | HARNESS, WIRING - CAB DASH | 1 | ||||
| ? | 58E-06-05885 | HARNESS, WIRING - OPERATOR CONTROL | 1 | ||||
| ? | 58E-06-05896 | HARNESS, WIRING - CENTER CONSOLE | 1 | ||||
| ? | 58E-06-11112 | CABLE, RADIO ANTENNA | 1 | ||||
| ? | 58E-06-50070 | SWITCH, PUSH-PULL | 1 | ||||
| ? | 58B-06-20020 | BRACKET | 2 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 7 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 11 | ||||
| ? | PC0616 | RECEPTACLE, TEE | 4 | ||||
| ? | PC0618 | PLUG, TERMINATING | 2 | ||||
| ? | XB6447 | PLUG, 3-POSITION | 4 | ||||
| ? | 58E-06-02203 | HARNESS, WIRING - POWER WINDOW (RH DOOR) | 1 | ||||
| ? | 58E-06-02193 | HARNESS, WIRING - POWER WINDOW (LH DOOR) | 1 | ||||
| ? | VC6467 | GROMMET, RUBBER | 4 | ||||
| ? | TG2960 | CLAMP, VINYL - 1/2" | 2 | ||||
| ? | MM0582 | CAPSCREW - M6 X 1.00 X 20 | 2 | ||||
| ? | 58E-54-21420 | WASHER, FENDER - M6 | 2 | ||||
| ? | SL9490 | GROMMET, RUBBER | 2 | ||||
| ? | 58E-06-11570 | SWITCH, DOOR | 2 | ||||
| ? | 58E-06-09231 | HARNESS, WIRING - WASHER FLUID TANK | 1 | ||||
| ? | WB3098 | CLAMP, CUSHIONED - 3/8" | 1 | ||||
| ? | 01023-60312 | SCREW | 2 | ||||
| ? | 58D-09-80400 | FLAT WASHER - #4 | 2 | ||||
| ? | MM0370 | NUT - M3 X 0.5 | 2 |
