Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
58E-54-06714 |
STEERING COLUMN (SEE INDEX) |
1 |
|
64612 |
|
|
? |
58E-54-31810 |
SCREW - M4 X 0.7 X 12 |
7 |
|
|
|
|
? |
58E-54-31981 |
GAP COVER PLATE |
1 |
|
|
|
|
? |
01252-71030 |
BOLT |
4 |
|
|
|
|
? |
MM0713 |
FLAT WASHER, HARDENED - M10 |
4 |
|
|
|
|
? |
WB1304 |
CLAMP, CUSHIONED - 9/16" |
2 |
|
|
|
|
? |
58E-54-21420 |
WASHER, FENDER - M6 |
4 |
|
|
|
|
? |
58E-09-00360 |
LOCKNUT, NYLON - M6 X 1.00 |
2 |
|
|
|
|
? |
58E-06-20402 |
TURN SIGNAL WIPER CONTROL SWITCH |
1 |
|
|
|
|
? |
58F-09-00000 |
CAPSCREW - M5 X 0.8 X 25 |
2 |
|
|
|
|
? |
WB3104 |
FLAT WASHER - M5 |
7 |
|
|
|
|
? |
WB3103 |
LOCKWASHER - M5 |
2 |
|
|
|
|
? |
MM0373 |
NUT - M5 X 0.8 |
2 |
|
|
|
|
? |
TD2186 |
GROMMET, RUBBER |
1 |
|
|
|
|
? |
58E-54-31873 |
BRACKET, SPEED CONTROL SWITCH |
1 |
|
|
|
|
? |
58E-06-60203 |
SPEED CONTROL SWITCH |
1 |
|
|
|
|
? |
MM0351 |
MACHINE SCREW - M5 X 0.8 X 20 |
3 |
|
|
|
|
? |
58E-54-06620 |
SPACER |
1 |
|
|
|
|
? |
01584-00504 |
NUT |
3 |
|
|
|
|
? |
MM0580 |
CAPSCREW - M6 X 1.00 X 14 |
4 |
|
|
|
|
? |
MM0459 |
FLAT WASHER - M6 |
2 |
|
|
|
|
? |
58E-54-31971 |
BEARING |
1 |
|
|
|
|
? |
58E-54-31823 |
BRACKET, SWITCH MOUNTING |
1 |
|
|
|
|
? |
1259564H1 |
SPLICE, JIFFY - #16 |
1 |
|
|
|
|
? |
58E-54-25344 |
COVER, STEERING COUPLING |
1 |
|
|
|
|
? |
WB1300 |
CLAMP, CUSHIONED - 5/8" |
1 |
|
|
|
|
? |
WB1302 |
CLAMP, CUSHIONED - 5/16" |
1 |
|
|
|
|
? |
MM0610 |
CAPSCREW - M10 X 1.50 X 50 |
2 |
|
|
|
|
? |
MM0461 |
FLAT WASHER - M10 |
2 |
|
|
|
|
? |
EL3892 |
SPACER |
1 |
|
|
|
|
? |
TY8375 |
SPACER |
1 |
|
|
|
|
? |
58B-06-20020 |
BRACKET |
2 |
|
|
|
|
? |
58E-54-31471 |
MOUNTING BRACKET, HORN SWITCH |
4 |
|
|
|
|
? |
01023-60320 |
SCREW |
2 |
|
|
|
|
? |
58D-09-80400 |
FLAT WASHER - #4 |
2 |
|
|
|
|
? |
MM0370 |
NUT - M3 X 0.5 |
2 |
|
|
|
