Номер на схеме	Каталожный номер	Название	Количество
?	58E-54-19304	PANEL, DASH	1
?	58E-54-19322	PANEL, DASH - TOP	1
?	58E-54-25530	PANEL, DASH - RH	1
?	58E-09-00350	SCREW - M4 X 0.7 X 12	8
?	PB8658	CAPSCREW - M6 X 1.00 X 30	34
?	PB9829	CAPSCREW - M6 X 1.00 X 16	17
?	58E-54-19333	PANEL, DASH - LOWER	1
?	58E-54-25350	PLATE, DASH SWITCH - LH	1
?	58E-54-18815	PANEL, LOWER DASH	1
?	58E-54-19524	PANEL, DASH	1
?	58E-54-13384	BRACKET	1
?	58E-54-13006	BRACKET	1
?	58E-54-25131	BRACKET, LH	1
?	58E-54-41244	BRACKET	1
?	58E-54-18744	PANEL, DASH - FRONT	1
?	58E-54-25302	BRACKET	1
?	58E-54-25201	BRACKET	1
?	MM0461	FLAT WASHER - M10	12
?	MM0605	CAPSCREW - M10 X 1.50 X 25	12
?	58E-54-25121	BRACKET, RH	1
?	MM0581	CAPSCREW - M6 X 1.00 X 16	4
?	58E-54-21420	WASHER, FENDER - M6	18
?	58E-54-25230	BRACKET	1
?	58E-54-25522	BRACKET	1
?	58E-54-11544	BRACKET	1
?	58E-54-27161	BRACKET	1
?	MM0582	CAPSCREW - M6 X 1.00 X 20	14
?	58E-54-03370	NUT	25
?	58E-54-13493	COVER, DASH	1
?	58E-54-25360	PLATE, DASH SWITCH - RH	1
?	58E-54-25381	PLATE, LOGO	1
?	58E-54-13930	NUT	5
?	58E-54-18713	PANEL, DASH	1
?	58E-54-25571	SEAL, STRIP	4
?	WA3134	SCREW, DRIVE - #6 X 3/16"	6
?	58E-54-27150	PLATE, DASH DECAL	1
?	58E-54-40032	PLATE, DASH CENTER	1
?	58E-54-41850	PLATE	1
