| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE0688 | PLATE, END | 1 | ||||
| ? | 58D-43-00650 | WEIGHT, BALANCE | |||||
| ? | 58D-43-00660 | WEIGHT, BALANCE | |||||
| ? | 58D-43-00700 | COIL, ROTOR W/ POLE PIECE | 1 | ||||
| ? | 58D-43-00670 | CORE, ROTOR | 1 | ||||
| ? | XA4156 | COLLECTOR RING ASSEMBLY | 1 | ||||
| ? | 58D-43-00680 | CORE, ROTOR W/ SHAFT | 1 | ||||
| ? | GE1084 | SHAFT, ROTOR | 1 | ||||
| ? | 58D-43-00690 | BEARING ASSEMBLY | 1 | ||||
| ? | 58D-43-00740 | • SENSOR, SPEED | 1 | ||||
| ? | 58D-43-00720 | • SEAL | 2 | ||||
| ? | XA4511 | • SEAL, V-RING (1) | 1 | ||||
| ? | 58D-43-00750 | • HOUSING, BEARING | 1 | ||||
| ? | 58D-43-00730 | • GASKET | 1 | ||||
| ? | 58D-43-00760 | • CAP, BEARING | 1 | ||||
| ? | VE5184 | • FLAT WASHER | 6 | ||||
| ? | 58D-43-00770 | • CAPSCREW - 5/8" - 11NC X 3 1/4" | 6 | ||||
| ? | 58E-06-03080 | • PACKING (1) | 1 | ||||
| ? | XA4332 | • SLEEVE | 1 | ||||
| ? | 58F-43-03130 | • BEARING, BALL | 1 | ||||
| ? | 58F-MA-AK010 | NOTE: (1) INCLUDED IN 58F-MA-AK010 ALTERNATOR OVERHAUL KIT. |
