| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 11Y-27-40402 | Final Drive Assembly | 1 | SN: 80512- KIT-FLAG: _- SCC: SERIALNO: 80512- |
|||
| ? | 11Y-27-40401 | Final Drive Assembly | 1 | SN: 80179-80511 KIT-FLAG: _- SCC: A1 SERIALNO: 80179-80511 |
|||
| ? | 706-8F-01140 | • Motor Assembly | 1 | SN: 80179- KIT-FLAG: _- SCC: SERIALNO: 80179- |
|||
| ? | (706-8F-41340) | • • Shaft, Drive | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-86-43880) | • • Bearing | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (20T-26-71221) | • • Bearing | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-86-43710) | • • Plate | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-8F-41350) | • • Spacer Kit | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | • • • Spacer, T=1.5mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.55mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.6mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.65mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.7mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.75mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.8mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.85mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.9mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.95mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=2.0mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=2.05mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=2.1mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=2.15mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=2.2mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=2.25mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=2.3mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | (04064-05020) | • • Ring, Snap | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-7G-11291) | • • Seal, Oil | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-8F-41480) | • • Spacer | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (04065-07225) | • • Ring, Snap | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-8F-41490) | • • Spacer Kit | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | • • • Spacer, T=0.9mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.0mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.1mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.2mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.3mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.4mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.5mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.6mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.7mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.8mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=1.9mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | • • • Spacer, T=2.0mm | 1 | SN: 80179- KIT-FLAG: _- SCC: C1 SERIALNO: 80179- |
||||
| ? | (706-8F-41230) | • • Shaft | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-8F-41240) | • • Race | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-8F-41250) | • • Spring | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-8F-41640) | • • Retainer | 1 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-75-42270) | • • Screw | 7 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
|||
| ? | (706-8F-41260) | • • Piston Subassembly | 7 | SN: 80179- KIT-FLAG: _- SCC: C2 SERIALNO: 80179- |
