| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 08000-01215 | BATTERY (145G51) | 2 | SN: 10001-@ |
|||
| ? | 385-10151091 | BATTERY,(FOR COLD WEATHER) | 2 | SN: 10001-@ |
|||
| ? | 380-127823-1 | ANGLE | 2 | SN: 10001-@ |
|||
| ? | 380-167548-1 | ROD | 4 | SN: 10001-@ |
|||
| ? | 382-025532-1 | WASHER | 4 | SN: 10001-@ |
|||
| ? | 382-026110-1 | NUT | 4 | SN: 10001-@ |
|||
| ? | 385-10254811 | LAMP,COMBINATION | 2 | SN: 10328-@ |
|||
| ? | 385-10051701 | LAMP,COMBINATION | 2 | SN: 10001-10327 |
|||
| ? | 385-10051711 | • BULB ? 6W | 2 | SN: 10001-@ |
|||
| ? | 08105-12420 | • BULB ? 25W | 1 | SN: 10001-@ |
|||
| ? | 385-10051721 | • LENS | 1 | SN: 10001-@ |
|||
| ? | 384-0115707 | • WASHER | 3 | SN: 10001-@ |
|||
| ? | 384-0120361 | • NUT | 3 | SN: 10001-@ |
|||
| ? | 385-10051792 | BOX | 2 | SN: 10001-@ |
|||
| ? | 382-024860-1 | BOLT | 8 | SN: 10001-@ |
|||
| ? | 382-025536-1 | WASHER | 8 | SN: 10001-@ |
|||
| ? | 380-888143-3 | LAMP,WORKING | 2 | SN: 10001-@ |
|||
| ? | 08113-02480 | • BULB ? 80W | 1 | SN: 10001-@ |
|||
| ? | 385-10359061 | SUPPORT,REAR LAMP | 1 | SN: 10328-@ |
|||
| ? | 385-10174191 | SUPPORT,REAR LAMP | 1 | SN: 10001-10327 |
|||
| ? | 382-024861-1 | BOLT | 4 | SN: 10001-@ |
|||
| ? | 382-025546-1 | WASHER | 4 | SN: 10001-@ |
|||
| ? | 385-10237022 | SUPPORT,L.H. | 1 | SN: 10136-@ |
|||
| ? | □385-10237021 | SUPPORT,L.H. | 1 | SN: 10001-10135 |
|||
| ? | 385-10363311 | SUPPORT,R.H. | 1 | SN: 10400-@ |
|||
| ? | 385-10237032 | SUPPORT,R.H. | 1 | SN: 10136-10399 |
|||
| ? | □385-10237031 | SUPPORT,R.H. | 1 | SN: 10001-10135 |
|||
| ? | 382-024861-1 | BOLT | 4 | SN: 10001-@ |
|||
| ? | 382-025546-1 | WASHER | 4 | SN: 10001-@ |
|||
| ? | 385-10224411 | SWITCH,TORQUE CONVERTER | 1 | SN: 10001-@ |
|||
| ? | 385-10051642 | SENSOR,TORQUE CONVERTER OIL TEMP. | 1 | SN: 10328-@ |
|||
| ? | 385-11015831 | SENDER,TORQUE CONVERTER OIL TEMP. | 1 | SN: 10001-10327 |
|||
| ? | 385-10224401 | SWITCH,THERMO | 1 | SN: 10001-@ |
|||
| ? | 08088-10000 | SWITCH,BATTERY RELAY | 1 | SN: 10001-@ |
|||
| ? | 382-025228-1 | NUT | 2 | SN: 10001-@ |
|||
| ? | 382-025533-1 | WASHER | 4 | SN: 10001-@ |
|||
| ? | 382-025520-1 | NUT | 2 | SN: 10001-@ |
|||
| ? | (08073-00505) | SWITCH | 1 | SN: 10001-@ |
|||
| ? | 385-10051642 | SENSOR,ENGINE WATER TEMPERATURE | 1 | SN: 10328-@ |
|||
| ? | 381-121756-2 | SENDER,ENGINE WATER TEMPERATURE | 1 | SN: 10211-10327 |
|||
| ? | □381-121756-1 | SENDER,ENGINE WATER TEMPERATURE | 1 | SN: 10001-10210 |
|||
| ? | 385-11328481 | SWITCH,OIL PRESSURE | 1 | SN: 10001-49999 |
|||
| ? | 380-885320-2 | ADAPTER | 2 | SN: 10328-@ |
|||
| ? | 381-970605-2 | LAMP | 1 | SN: 10328-@ |
|||
| ? | 08105-12420 | BULB ? 25W | 1 | SN: 10328-@ |
|||
| ? | 381-976941-1 | LENS | 1 | SN: 10328-@ |
