| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-1S-00940 | Pump Assembly, Fan | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: A4 SERIALNO: 65001-65939 |
|||
| ? | (708-1S-12320) | Shaft | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (706-73-40890) | Bearing | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1S-12260) | Bearing | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65939 |
|||
| ? | (708-7T-05020) | Spacer Kit | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65939 |
|||
| ? | • Spacer, T=1.6mm | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65939 |
||||
| ? | • Spacer, T=1.7mm | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65939 |
||||
| ? | • Spacer, T=1.8mm | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65939 |
||||
| ? | • Spacer, T=1.9mm | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65939 |
||||
| ? | • Spacer, T=2.0mm | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65939 |
||||
| ? | • Spacer, T=2.1mm | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65939 |
||||
| ? | • Spacer, T=2.2mm | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65939 |
||||
| ? | (708-1S-12280) | Ring, Wear | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65939 |
|||
| ? | (708-1S-12330) | Retainer | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65939 |
|||
| ? | (708-1S-12340) | Case | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | 708-1T-11880 | Seal, Oil | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: SERIALNO: 65001-65939 |
|||
| ? | 207-09-11140 | O-ring | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: SERIALNO: 65001-65939 |
|||
| ? | 04065-06220 | Ring, Snap | 1 | SN: 65001-@ KIT-FLAG: _- SCC: SERIALNO: 65001-@ |
|||
| ? | (708-1S-13130) | Block, Cylinder | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1S-13450) | Plate, valve | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-3S-13160) | Washer | 2 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-3S-13430) | Spring | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (04065-03515) | Ring, Snap | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1S-13370) | Guide, Retainer | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1S-13380) | Pin | 3 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1S-13360) | Retainer, Shoe | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1S-13320) | Piston Subassembly | 7 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1S-14210) | Plug | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65939 |
|||
| ? | (708-3S-14261) | Plug | 1 | SN: 65001-65939 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65939 |
|||
| ? | (07002-11223) | O-ring | 2 | SN: 65001-65939 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65939 |
|||
| ? | (708-3S-14290) | Piston Subassembly | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1S-14241) | Spring | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
