| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 708-1W-00883 | Pump Assembly | 1 | SN: 65535-65570 KIT-FLAG: _- SCC: A2 SERIALNO: 65535-65570 |
|||
| ? | 708-1W-00882 | Pump Assembly | 1 | SN: 65001-65534 KIT-FLAG: _- SCC: A2 SERIALNO: 65001-65534 |
|||
| ? | (708-1W-01885) | • Pump Subassembly | 1 | SN: 65535-65570 KIT-FLAG: _- SCC: C2 SERIALNO: 65535-65570 |
|||
| ? | (708-1W-01884) | • Pump Subassembly | 1 | SN: 65001-65534 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65534 |
|||
| ? | (708-1W-04921) | • • Case Assembly | 1 | SN: 65001-65570 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65570 |
|||
| ? | • • • Case, Pump | 1 | SN: 65001-65570 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65570 |
||||
| ? | • • • Plug | 5 | SN: 65001-65570 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65570 |
||||
| ? | • • • Sleeve | 1 | SN: 65001-65570 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65570 |
||||
| ? | • • • Ring | 1 | SN: 65001-65570 KIT-FLAG: _- SCC: C1 SERIALNO: 65001-65570 |
||||
| ? | 708-8E-16160 | • • Plug | 1 | SN: 65001-@ KIT-FLAG: _- SCC: SERIALNO: 65001-@ |
|||
| ? | 07002-11023 | • • O-ring | 1 | SN: 65001-@ KIT-FLAG: _- SCC: SERIALNO: 65001-@ |
|||
| ? | 07040-11409 | • • Plug | 1 | SN: 65001-@ KIT-FLAG: _- SCC: SERIALNO: 65001-@ |
|||
| ? | 07002-11423 | • • O-ring | 1 | SN: 65001-@ KIT-FLAG: _- SCC: SERIALNO: 65001-@ |
|||
| ? | (706-73-42370) | • • O-ring | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (07000-B1009) | • • O-ring | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (04020-01024) | • • Pin, Dowel | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (01010-61470) | • • Bolt | 4 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (01643-31445) | • • Washer, Flat | 4 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1W-41570) | • • Cap, End | 1 | SN: 65001-65570 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65570 |
|||
| ? | (708-1W-42120) | • • Bearing | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-3T-13421) | • • Ball | 2 | SN: 65001-65570 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65570 |
|||
| ? | (708-1W-43412) | • • Cam, Rocker | 1 | SN: 65001-65570 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65570 |
|||
| ? | (04260-01270) | • • Ball | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1U-12110) | • • Shaft | 1 | SN: 65001-65570 KIT-FLAG: _- SCC: C2 SERIALNO: 65001-65570 |
|||
| ? | (708-1W-42110) | • • Bearing | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | (708-1W-42140) | • • Case, Seal | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | 708-1W-42130 | • • Seal, Oil | 1 | SN: 65001-@ KIT-FLAG: _- SCC: SERIALNO: 65001-@ |
|||
| ? | 07000-B2060 | • • O-ring | 1 | SN: 65001-@ KIT-FLAG: _- SCC: SERIALNO: 65001-@ |
|||
| ? | (708-1W-05821) | • • Spacer Kit | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C2 SERIALNO: 65001-@ |
|||
| ? | • • • Spacer, T=2.5mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | • • • Spacer, T=2.55mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | • • • Spacer, T=2.6mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | • • • Spacer, T=2.65mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | • • • Spacer, T=2.7mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | • • • Spacer, T=2.75mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | • • • Spacer, T=2.8mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | • • • Spacer, T=2.85mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | • • • Spacer, T=2.9mm | 1 | SN: 65001-@ KIT-FLAG: _- SCC: C1 SERIALNO: 65001-@ |
||||
| ? | 04065-06825 | • • Ring, Snap | 1 | SN: 65001-@ KIT-FLAG: _- SCC: SERIALNO: 65001-@ |
