| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6204-71-1610) | INJECTION PUMP A.,(SEE FIG. 0451) | 1 | SN: 18897- |
|||
| ? | 6204-71-3610 | GEAR | 1 | SN: 18897- |
|||
| ? | 6204-71-3630 | NUT | 1 | SN: 18897- |
|||
| ? | 6114-31-3330 | WASHER,LOCK (K2) | 1 | SN: 68095- |
|||
| ? | □01653-21212 | WASHER,LOCK | 1 | SN: 41315-68094 |
|||
| ? | □01653-21212 | WASHER,LOCK (K2) | 1 | SN: 18897-41314 |
|||
| ? | 6204-71-3110 | HOLDER | 1 | SN: 18897- |
|||
| ? | 07000-02135 | O-RING (K2) | 1 | SN: 18897- |
|||
| ? | 6204-71-3190 | BOLT | 1 | SN: 18897- |
|||
| ? | 01435-20812 | BOLT | 1 | SN: 18897- |
|||
| ? | 07005-00812 | GASKET (K2) | 1 | SN: 18897- |
|||
| ? | 07000-02065 | O-RING (K2) | 1 | SN: 18897- |
|||
| ? | 01144-31035 | STUD | 4 | SN: 18897- |
|||
| ? | 01584-21008 | NUT | 4 | SN: 18897- |
|||
| ? | 6206-71-1852 | BRACKET | 1 | SN: 18897- |
|||
| ? | 01435-21016 | BOLT | 1 | SN: 18897- |
|||
| ? | 01584-20806 | NUT | 1 | SN: 18897- |
|||
| ? | 6204-71-5110 | TUBE,INJECTION ? NO.1 | 1 | SN: 18897- |
|||
| ? | 6204-71-5120 | TUBE,INJECTION ? NO.2 | 1 | SN: 18897- |
|||
| ? | 6204-71-5130 | TUBE,INJECTION ? NO.3 | 1 | SN: 18897- |
|||
| ? | 6204-71-5140 | TUBE,INJECTION ? NO.4 | 1 | SN: 18897- |
|||
| ? | 6204-71-5810 | PLATE | 1 | SN: 18897- |
|||
| ? | 01435-20612 | BOLT | 2 | SN: 18897- |
|||
| ? | 6204-71-5710 | CLAMP | 2 | SN: 18897- |
|||
| ? | 01435-20625 | BOLT | 2 | SN: 18897- |
|||
| ? | 6204-71-4230 | PIPE,OIL | 1 | SN: 18897- |
|||
| ? | 6204-71-4250 | CONNECTOR | 1 | SN: 18897- |
|||
| ? | 07206-30710 | BOLT,JOINT | 1 | SN: 18897- |
|||
| ? | 07005-01012 | GASKET (K2) | 2 | SN: 18897- |
|||
| ? | (09920-00150) | LIQUID GASKET,LG-7 ? 150G | A/R | SN: 18897- |
