| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6219-51-1000 | PUMP ASSEMBLY | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | PML160-11600 | • GEAR AND CASE ASSEMBLY | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | PML150-08400 | • • CASE ASSEMBLY | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | • • • CASE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | PML130-00220 | • • • BUSHING | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | PML154-09500 | • • GEAR ASSEMBLY, DRIVE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | • • • GEAR | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | • • • SHAFT, DRIVE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | PML124-06600 | • • GEAR | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | PML156-07700 | • • GEAR ASSEMBLY, DRIVEN | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | • • • GEAR | 2 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | • • • BUSHING | 2 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | PML152-07400 | • • COVER ASSEMBLY | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | PML152-07500 | • • • COVER ASSEMBLY | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | • • • • COVER | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | • • • BUSHING | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | PML112-00411 | • • • SHAFT | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | PML142-01700 | • • • RING | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | PMMF14-0227 | • • BOLT | 5 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01437-01245 | BOLT | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01437-01280 | BOLT | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 07000-E3050 | O-RING | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-51-2700 | VALVE ASSEMBLY | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-51-2710 | • BODY | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-51-2740 | • PLUG | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-51-2730 | • VALVE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-51-2750 | • SPRING | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6215-51-1780 | GASKET | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01437-01030 | BOLT | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01437-01060 | BOLT | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
