| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-815-2690 | SWITCH,HEATER | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01010-80816 | BOLT | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-30823 | WASHER | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-81-6670 | COVER | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-81-8610 | PLATE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01010-81030 | BOLT | 4 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01010-80812 | BOLT | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-30823 | WASHER | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-81-8180 | WIRE | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01010-81020 | BOLT | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-81-8140 | WIRE | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-81-6390 | BRACKET | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01010-81030 | BOLT | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-81-6370 | COVER | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6150-71-7130 | COLLAR | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01011-81015 | BOLT | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
