| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | LEVER ASSEMBLY | 24 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | • LEVER | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | • SOCKET | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | • ROLLER, CAM | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | • PIN, ROLLER | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | 6210-41-2400 | SHAFT ASSEMBLY | 12 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | • SHAFT | 1 | Field_1: Field_2: 505792 Field_3: Field_4: C1 |
||||
| ? | 6150-81-8420 | • BALL | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 04064-02212 | RING,SNAP | 48 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6210-41-2450 | BOLT | 24 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6210-41-2431 | PIN,DOWEL | 24 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6210-41-3120 | ROD,PUSH | 24 | Field_1: Field_2: 505792 Field_3: Field_4: |
