| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6219-11-5780 | COVER | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 09817-A1103 | • PLATE,WARNING,HIGH TEMPERATURE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01010-E1040 | BOLT | 8 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-31032 | WASHER | 8 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6261-11-8280 | COVER, TURBINE R.H. | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 09817-A1103 | • PLATE,WARNING,HIGH TEMPERATURE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-11-8240 | COVER, TURBINE L.H. | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 09817-A1103 | • PLATE,WARNING,HIGH TEMPERATURE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-11-5790 | PLATE | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6137-71-3750 | SPACER | 4 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01435-00895 | BOLT | 4 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-21-6410 | PLATE | 8 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-21-6420 | PLATE | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-21-6450 | BOLT | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01435-01025 | BOLT | 19 | Field_1: Field_2: 505792 Field_3: Field_4: |
