| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6219-71-5820 | TUBE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-71-5830 | TUBE | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-71-7840 | TUBE, SUPPLY | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6934-72-7190 | BOLT,JOINT | 4 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 07005-01012 | SEAL,WASHER | 8 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6212-65-8860 | ADAPTER | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6215-81-9720 | O-RING | 2 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-71-4530 | BRACKET | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01010-81070 | BOLT | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-31032 | WASHER | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-71-7870 | BRACKET | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6219-71-7880 | BRACKET | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01010-81025 | BOLT | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-31032 | WASHER | 1 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 6934-72-5661 | CLAMP | 6 | Field_1: Field_2: 507094 Field_3: Field_4: |
|||
| ? | 6934-72-5660 | CLAMP | 6 | Field_1: Field_2: 505792 Field_3: 507093 Field_4: |
|||
| ? | 01010-81045 | BOLT | 3 | Field_1: Field_2: 505792 Field_3: Field_4: |
|||
| ? | 01643-31032 | WASHER | 3 | Field_1: Field_2: 505792 Field_3: Field_4: |
