Содержание Dump Trucks Komatsu HD785-NI-7 S/N N10561-UP(KIPL0001)
FUEL SUPPLY PUMP (INNER PARTS, FUEL SUPPLY PUMP, L.H.) (2/2)(|A00101 : |A00101)
Номер на схеме Каталожный номер Название Количество Детали
? 6219-71-1101 PUMP ASSEMBLY, L.H. 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? 6219-71-1111 • PUMP,SUPPLY 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? (ND094100-0512) • • BODY ASSEMBLY 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094110-0230) • • • HOUSING ASSEMBLY 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094040-0380) • • • ELEMENT ASSEMBLY 2
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094086-0090) • • • • O-RING 2
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094140-0040) • • • • VALVE ASSEMBLY 2
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094086-0100) • • • O-RING 4
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND949013-5880) • • • WASHER 4
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND92156-08081) • • • NUT 4
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094162-0031) • • • SEAT,SPRING 2
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094164-0030) • • • SPRING 2
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094165-0031) • • • SEAT,SPRING 2
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094170-0110) • • • TAPPET ASSEMBLY 2
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094191-0590) • • • CAMSHAFT 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND949101-0250) • • • BEARING,ROLLER 2
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094104-0160) • • • COVER 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND949150-3200) • • • SEAL,OIL 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094086-0150) • • • O-RING 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094095-0330) • • • SHIM, T=0.05MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094095-0340) • • • SHIM, T=0.10MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094095-0350) • • • SHIM, T=0.20MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094095-0360) • • • SHIM, T=0.30MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094095-0370) • • • SHIM, T=0.50MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094092-0010) • • • WASHER 4
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND949044-3320) • • • BOLT 4
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094086-0160) • • • O-RING 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094086-0170) • • • O-RING 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094093-0090) • • • SHIM, T=0.40MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094093-0100) • • • SHIM, T=0.60MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094093-0110) • • • SHIM, T=0.80MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094093-0120) • • • SHIM, T=1.00MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND949979-1300) • • • SENSOR ASSEMBLY 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND949140-6310) • • • • O-RING 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094096-0050) • • • SHIM, T=0.15MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094096-0060) • • • SHIM, T=0.20MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094096-0070) • • • SHIM, T=0.25MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND094096-0080) • • • SHIM, T=0.40MM A/R
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND90200-06081) • • • WASHER 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? (ND90107-06161) • • • BOLT 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? ND090310-0500 • • • VALVE ASSEMBLY 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? ND090222-0070 • • • WASHER 5
Field_1:
Field_2: 505792
Field_3:
Field_4:
? ND949180-0310 • • • SCREW 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? ND090222-0120 • • • WASHER 2
Field_1:
Field_2: 505792
Field_3:
Field_4:
? ND949180-0060 • • • SCREW 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? ND949018-0350 • • • WASHER 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? ND090317-0480 • • • PLUG 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? (ND090207-0100) • • • RING 1
Field_1:
Field_2: 505792
Field_3:
Field_4: C2
? ND090244-0010 • • • SCREW 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? ND949010-3020 • • • WASHER 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
? ND094086-0210 • • O-RING 1
Field_1:
Field_2: 505792
Field_3:
Field_4:
