Содержание Excavators Komatsu PC300-8M0 S/N J40001-UP(KI-00011)
CAB (ROOF WINDOW)(|K0270150 : |K0270150)
Номер на схеме Каталожный номер Название Количество Детали
? 207-53-00651 CAB ASS'Y 1
Field_1:
Field_2: J40035
Field_3:
Field_4:
? 207-53-00561 CAB ASS'Y 1
Field_1:
Field_2: J40018
Field_3: J40034
Field_4:
? 207-53-00560 CAB ASS'Y 1
Field_1:
Field_2: J40001
Field_3: J40017
Field_4:
? 2A5-53-12412 • ROOF 1
Field_1:
Field_2: J40035
Field_3:
Field_4:
? 208-53-22710 • ROOF 1
Field_1:
Field_2: J40001
Field_3: J40034
Field_4:
? 2A5-53-11K11 • • HINGE, WELDED 1
Field_1:
Field_2: J40035
Field_3:
Field_4:
? 208-53-22H70 • • HINGE 2
Field_1:
Field_2: J40001
Field_3: J40034
Field_4:
? 2A5-53-11K21 • • HINGE, WELDED 1
Field_1:
Field_2: J40035
Field_3:
Field_4:
? 01584-30806 • NUT 4
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-53-11921 • COVER (ROOF) 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 09416-10200 • BUTTAN 5
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-53-11741 • CLEAR PLATE 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-53-11790 • SEAL (DAM) 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 2A5-53-11471 • SEAL 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-54-14590 • HANDLE 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 01245-00616 • SCREW 2
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 01643-70623 • WASHER 2
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-53-11721 • LOCK A.(ROOF) 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-53-11781 • KNOB 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 01435-40610 • BOLT 3
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-53-11931 • COVER(ROOF LOCK 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 22B-54-38541 • SPRING GAS 2
Field_1:
Field_2: J40035
Field_3:
Field_4:
? 208-53-22162 • SPRING GAS 2
Field_1:
Field_2: J40001
Field_3: J40034
Field_4:
? 2A5-53-12530 • PIN, SNAP 4
Field_1:
Field_2: J40035
Field_3:
Field_4:
? 04052-10833 • PIN, SNAP 4
Field_1:
Field_2: J40001
Field_3: J40034
Field_4:
? 20Y-53-11771 • STRIKER 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 01245-00820 • SCREW 2
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-54-52651 • SPACER 2
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-53-11861 • SEAL 1
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 01643-70823 • WASHER 2
Field_1:
Field_2: J40035
Field_3:
Field_4:
? 01245-00620 • SCREW 4
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 01643-70623 • WASHER 4
Field_1:
Field_2: J40001
Field_3:
Field_4:
? 20Y-54-52651 • SPACER 4
Field_1:
Field_2: J40001
Field_3:
Field_4:
