| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20Y-06-25310 | WORK LAMP ASS'Y | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 421-06-23330 | • BULB | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 20Y-06-21551 | BRACKET | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 01010-81225 | BOLT | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 01643-31232 | WASHER | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 203-06-71171 | WIRING HARNESS | 1 | Field_1: Field_2: J10362 Field_3: Field_4: |
|||
| ? | 203-06-57230 | WIRING HARNESS | 1 | Field_1: Field_2: J10001 Field_3: J10361 Field_4: |
|||
| ? | 01010-81230 | BOLT | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 01643-31232 | WASHER | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 203-06-56570 | BAND | 2 | Field_1: Field_2: J10001 Field_3: J10361 Field_4: |
|||
| ? | 08034-40521 | BAND | 2 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 08034-20414 | BAND | 9 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 202-70-J2140 | PIN | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 205-70-66580 | PLATE | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 01010-81230 | BOLT | 2 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 01643-31232 | WASHER | 2 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 20U-70-31340 | SPACER, 1.0MM | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 20U-70-31330 | SPACER, 0.5MM | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 203-70-42121 | PIN | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 205-70-66580 | PLATE | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 01010-81230 | BOLT | 2 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 01643-31232 | WASHER | 2 | Field_1: Field_2: J10001 Field_3: Field_4: |
|||
| ? | 203-70-41461 | SPACER | 1 | Field_1: Field_2: J10001 Field_3: Field_4: |
