| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-813-6632 | STARTING MOTOR ASSEMBLY, 7.5KW | 1 | Field_1: STARTING MOTOR ASSEMBLY, 7.5KW Field_2: 574420- code: |
|||
| ? | KD0-23904-0070 | • PIN | 1 | Field_1: PIN Field_2: 574420- code: |
|||
| ? | KD0-23927-0071 | • HOLDER | 2 | Field_1: HOLDER Field_2: 574420- code: |
|||
| ? | KD1-23914-0020 | • RING | 1 | Field_1: RING Field_2: 574420- code: |
|||
| ? | KD1-23181-0020 | • STOPPER | 1 | Field_1: STOPPER Field_2: 574420- code: |
|||
| ? | KD1-23111-0160 | • SHAFT | 1 | Field_1: SHAFT Field_2: 574420- code: |
|||
| ? | KD0-23310-0860 | • BRACKET | 1 | Field_1: BRACKET Field_2: 574420- code: |
|||
| ? | KD1-23500-0170 | • CLUTCH ASSEMBLY | 1 | Field_1: CLUTCH ASSEMBLY Field_2: 574420- code: |
|||
| ? | KD0-23951-0301 | • PACKING | 1 | Field_1: PACKING Field_2: 574420- code: |
|||
| ? | KD0-23320-0220 | • LEVER ASSEMBLY | 1 | Field_1: LEVER ASSEMBLY Field_2: 574420- code: |
|||
| ? | KD1-0456-60067 | • BEARING, BALL | 1 | Field_1: BEARING, BALL Field_2: 574420- code: |
|||
| ? | KD0-23951-0331 | • PACKING | 1 | Field_1: PACKING Field_2: 574420- code: |
|||
| ? | KD0-23600-0430 | • BRACKET ASSEMBLY | 1 | Field_1: BRACKET ASSEMBLY Field_2: 574420- code: |
|||
| ? | KD0-23611-0690 | • BRACKET | 1 | Field_1: BRACKET Field_2: 574420- code: |
|||
| ? | KD1-09211-0980 | • O-RING | 2 | Field_1: O-RING Field_2: 574420- code: |
|||
| ? | KD0-23921-0230 | • WASHER | 1 | Field_1: WASHER Field_2: 574420- code: |
|||
| ? | KD1-0454-62047 | • BEARING, BALL | 1 | Field_1: BEARING, BALL Field_2: 574420- code: |
|||
| ? | KD0-0274-06202 | • BOLT | 3 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | KD1-23951-0020 | • PACKING | 1 | Field_1: PACKING Field_2: 574420- code: |
|||
| ? | KD1-0400-20100 | • PIN | 1 | Field_1: PIN Field_2: 574420- code: |
|||
| ? | KD0-23100-0251 | • ARMATURE ASSEMBLY | 1 | Field_1: ARMATURE ASSEMBLY Field_2: 574420- code: |
|||
| ? | KD0-47100-4800 | • SWITCH ASSEMBLY, MAGNETIC | 1 | Field_1: SWITCH ASSEMBLY, MAGNETIC Field_2: 574420- code: |
|||
| ? | KD0-09271-3620 | • NAME PLATE | 1 | Field_1: NAME PLATE Field_2: 574420- code: |
|||
| ? | KD0-23200-0331 | • YOKE ASSEMBLY | 1 | Field_1: YOKE ASSEMBLY Field_2: 574420- code: |
|||
| ? | KD0-47761-2691 | • COVER | 1 | Field_1: COVER Field_2: 574420- code: |
|||
| ? | KD1-23913-0040 | • BRUSH | 4 | Field_1: BRUSH Field_2: 574420- code: |
|||
| ? | KD0-23740-0250 | • BRUSH ASSEMBLY | 4 | Field_1: BRUSH ASSEMBLY Field_2: 574420- code: |
|||
| ? | KD0-23750-0250 | • HOLDER ASSEMBLY, BRUSH | 1 | Field_1: HOLDER ASSEMBLY, BRUSH Field_2: 574420- code: |
|||
| ? | KD1-0505-00601 | • O-RING | 2 | Field_1: O-RING Field_2: 574420- code: |
|||
| ? | KD1-47921-0790 | • WASHER | 2 | Field_1: WASHER Field_2: 574420- code: |
|||
| ? | KD0-09001-4580 | • BOLT | 2 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | KD1-0454-62007 | • BEARING, BALL | 1 | Field_1: BEARING, BALL Field_2: 574420- code: |
|||
| ? | KD0-23700-0130 | • BRACKET ASSEMBLY | 1 | Field_1: BRACKET ASSEMBLY Field_2: 574420- code: |
|||
| ? | KD1-0240-06305 | • BOLT | 6 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | KD1-23921-0130 | • WASHER | 1 | Field_1: WASHER Field_2: 574420- code: |
|||
| ? | KD1-23921-0140 | • WASHER | 1 | Field_1: WASHER Field_2: 574420- code: |
|||
| ? | KD1-23941-0040 | • WASHER, INSULATE | 1 | Field_1: WASHER, INSULATE Field_2: 574420- code: |
|||
| ? | KD1-0240-08405 | • BOLT | 3 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | KD1-0335-08002 | • WASHER, SPRING | 3 | Field_1: WASHER, SPRING Field_2: 574420- code: |
|||
| ? | KD1-0330-08022 | • WASHER | 3 | Field_1: WASHER Field_2: 574420- code: |
