| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6151-61-3201 | CASE ASSEMBLY | 1 | Field_1: CASE ASSEMBLY Field_2: 574420- code: |
|||
| ? | 6151-61-3152 | • CASE | 1 | Field_1: CASE Field_2: 574420- code: |
|||
| ? | 6151-61-3120 | • HUB | 1 | Field_1: HUB Field_2: 574420- code: |
|||
| ? | 6151-61-3170 | • SHAFT | 1 | Field_1: SHAFT Field_2: 574420- code: |
|||
| ? | 01583-02414 | • NUT | 1 | Field_1: NUT Field_2: 574420- code: |
|||
| ? | 01643-32460 | • WASHER | 1 | Field_1: WASHER Field_2: 574420- code: |
|||
| ? | 06037-06307 | • BEARING, BALL | 1 | Field_1: BEARING, BALL Field_2: 574420- code: |
|||
| ? | 06037-06206 | • BEARING, BALL | 1 | Field_1: BEARING, BALL Field_2: 574420- code: |
|||
| ? | 04065-08025 | • RING, SNAP | 1 | Field_1: RING, SNAP Field_2: 574420- code: |
|||
| ? | 01435-01030 | BOLT | 4 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | 6151-61-3970 | COVER, DUST | 1 | Field_1: COVER, DUST Field_2: 574420- code: |
|||
| ? | 6251-61-3530 | PLATE | 1 | Field_1: PLATE Field_2: 574420- code: |
|||
| ? | 6631-11-5630 | SPACER | 2 | Field_1: SPACER Field_2: 574420- code: |
|||
| ? | 01011-81015 | BOLT | 2 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | 6251-61-3520 | BRACKET | 1 | Field_1: BRACKET Field_2: 574420- code: |
|||
| ? | 01011-81015 | BOLT | 4 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | 6251-61-3820 | BRACKET | 1 | Field_1: BRACKET Field_2: 574420- code: |
|||
| ? | 01435-01095 | BOLT | 2 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | 6251-21-3950 | PLATE, HANGER | 1 | Field_1: PLATE, HANGER Field_2: 574420- code: |
|||
| ? | 6166-61-6341 | GASKET | 1 | Field_1: GASKET Field_2: 574420- code: |
|||
| ? | 01435-01025 | BOLT | 6 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | 01435-01035 | BOLT | 4 | Field_1: BOLT Field_2: 574420- code: |
|||
| ? | 01435-01030 | BOLT | 2 | Field_1: BOLT Field_2: 574420- code: |
