Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество	Детали
?	203-26-80500	SWING MACHINERY ASSEMBLY	1	Field_1: SWING MACHINERY ASSEMBLY Field_2: DJE10001- code:
?	203-26-85000	• SWING MACHINERY ASSEMBLY	1	Field_1: SWING MACHINERY ASSEMBLY Field_2: DJE10001- code:
?	706-7C-01040	• • MOTOR ASSEMBLY	1	Field_1: MOTOR ASSEMBLY Field_2: DJE10001- code:
?	(706-7C-03040)	• • • MOTOR SUBASSEMBLY	1	Field_1: MOTOR SUBASSEMBLY Field_2: DJE10001- code: C2
?	(706-7C-71130)	• • • • CASE, MOTOR	1	Field_1: CASE, MOTOR Field_2: DJE10001- code: C2
?	(706-7C-71210)	• • • • HOUSING	1	Field_1: HOUSING Field_2: DJE10001- code: C2
?	(706-73-40010)	• • • • BEARING	1	Field_1: BEARING Field_2: DJE10001- code: C2
?	(706-73-42820)	• • • • PIN	1	Field_1: PIN Field_2: DJE10001- code: C2
?	706-7C-51110	• • • • VALVE	2	Field_1: VALVE Field_2: DJE10001- code:
?	706-7C-51120	• • • • SPRING	2	Field_1: SPRING Field_2: DJE10001- code:
?	706-7C-51130	• • • • PLUG	2	Field_1: PLUG Field_2: DJE10001- code:
?	07000-13024	• • • • O-RING	2	Field_1: O-RING Field_2: DJE10001- code:
?	708-7R-11220	• • • • PLUG	1	Field_1: PLUG Field_2: DJE10001- code:
?	07002-11223	• • • • O-RING	1	Field_1: O-RING Field_2: DJE10001- code:
?	702-21-55620	• • • • PLUG	2	Field_1: PLUG Field_2: DJE10001- code:
?	07002-11423	• • • • O-RING	2	Field_1: O-RING Field_2: DJE10001- code:
?	706-7C-51140	• • • • VALVE	2	Field_1: VALVE Field_2: DJE10001- code:
?	722-10-91130	• • • • SPRING	2	Field_1: SPRING Field_2: DJE10001- code:
?	706-7C-51150	• • • • PLUG	2	Field_1: PLUG Field_2: DJE10001- code:
?	07002-11823	• • • • O-RING	2	Field_1: O-RING Field_2: DJE10001- code:
?	(07000-12145)	• • • • O-RING	1	Field_1: O-RING Field_2: DJE10001- code: C2
?	(01252-61245)	• • • • BOLT, HEXAGON SOCKET HEAD	6	Field_1: BOLT, HEXAGON SOCKET HEAD Field_2: DJE10001- code: C2

Excavators Komatsu / PC130-8M0 S/N DJE10001-up(KC_EB010) / SWING MACHINERY AND MOTOR (SWING MOTOR) (1/3)(|N00348 : |N00348)
