Содержание Excavators Komatsu PC130-8M0 S/N DJE10001-up(KC_EB010)
CAB AND FLOOR FRAME GROUP (WITH 1-ADDITIONAL ACTUATOR PIPING, ACCUMULATOR) (PPC VALVE FOR ATTACHMENT)(|K00293 : |K00293)
Номер на схеме Каталожный номер Название Количество Детали
? 702-16-05260 VALVE, PILOT 1
Field_1: VALVE, PILOT
Field_2: DJE10001-
code:
? • BODY, VALVE 1
Field_1: BODY, VALVE
Field_2: DJE10001-
code: C1
? • VALVE 2
Field_1: VALVE
Field_2: DJE10001-
code: C1
? 702-16-51140 • SHIM, T=0.30MM 2
Field_1: SHIM, T=0.30MM
Field_2: DJE10001-
code:
? 702-16-54670 • SHIM, T=0.20MM 4
Field_1: SHIM, T=0.20MM
Field_2: DJE10001-
code:
? 702-16-54550 • SPRING 2
Field_1: SPRING
Field_2: DJE10001-
code:
? 702-16-54571 • RETAINER 2
Field_1: RETAINER
Field_2: DJE10001-
code:
? 702-16-54560 • SPRING 2
Field_1: SPRING
Field_2: DJE10001-
code:
? 702-16-53170 • PISTON 2
Field_1: PISTON
Field_2: DJE10001-
code:
? 702-16-51270 • SEAL 2
Field_1: SEAL
Field_2: DJE10001-
code:
? 702-16-54580 • COLLAR 2
Field_1: COLLAR
Field_2: DJE10001-
code:
? 702-16-54590 • O-RING 2
Field_1: O-RING
Field_2: DJE10001-
code:
? • LEVER 1
Field_1: LEVER
Field_2: DJE10001-
code: C1
? • PLATE 1
Field_1: PLATE
Field_2: DJE10001-
code: C1
? • SHAFT 1
Field_1: SHAFT
Field_2: DJE10001-
code: C1
? 702-16-54641 • BOOT 1
Field_1: BOOT
Field_2: DJE10001-
code:
? 01252-60625 • BOLT 2
Field_1: BOLT
Field_2: DJE10001-
code:
? 702-16-54660 • PLATE 1
Field_1: PLATE
Field_2: DJE10001-
code:
? 702-16-54650 • PLATE 2
Field_1: PLATE
Field_2: DJE10001-
code:
? 702-21-53780 • SOLENOID ASSEMBLY 1
Field_1: SOLENOID ASSEMBLY
Field_2: DJE10001-
code:
? • SPOOL 1
Field_1: SPOOL
Field_2: DJE10001-
code: C1
? • PLUG 1
Field_1: PLUG
Field_2: DJE10001-
code: C1
? 702-21-53311 • SPRING, L=9.5MM 1
Field_1: SPRING, L=9.5MM
Field_2: DJE10001-
code:
? 702-21-53340 • SPRING, L=9.1MM 1
Field_1: SPRING, L=9.1MM
Field_2: DJE10001-
code:
? 702-21-53350 • SPRING, L=9.9MM 1
Field_1: SPRING, L=9.9MM
Field_2: DJE10001-
code:
? 702-16-56490 • FILTER 1
Field_1: FILTER
Field_2: DJE10001-
code:
? • PLUG 2
Field_1: PLUG
Field_2: DJE10001-
code: C1
? 01252-60620 • BOLT, HEXAGON SOCKET HEAD 2
Field_1: BOLT, HEXAGON SOCKET HEAD
Field_2: DJE10001-
code:
