| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | ЧўЈєґЛБР±н°ьАЁТФПВ№жёсЎЈ | Field_1: Field_2: code: |
|||||
| ? | І»ґш1ёщёЅјУЦґРР»ъ№№№ЬВ·Ј¬РоДЬЖч | Field_1: Field_2: code: |
|||||
| ? | ґш1ёщёЅјУЦґРР»ъ№№№ЬВ·Ј¬РоДЬЖч | Field_1: Field_2: code: |
|||||
| ? | Note: This list covers following | Field_1: Field_2: code: |
|||||
| ? | Without 1-additional Actuator Pi | Accumulat | Field_1: Field_2: code: |
5 | |||
| ? | With 1-additional Actuator Pipin | Accumulator | Field_1: Field_2: code: |
6 | |||
| ? | 2A5-979-1113 | AIR CONDITIONER | 1 | Field_1: AIR CONDITIONER Field_2: DJE10001- code: |
|||
| ? | ND117300-2600 | • MOTOR ASSEMBLY | 1 | Field_1: MOTOR ASSEMBLY Field_2: DJE10001- code: |
|||
| ? | ND116242-7000 | • • CASE | 1 | Field_1: CASE Field_2: DJE10001- code: |
|||
| ? | ND116242-7010 | • • CASE | 1 | Field_1: CASE Field_2: DJE10001- code: |
|||
| ? | ND017321-4600 | • • CASE | 1 | Field_1: CASE Field_2: DJE10001- code: |
|||
| ? | ND116360-0030 | • • MOTOR ASSEMBLY | 1 | Field_1: MOTOR ASSEMBLY Field_2: DJE10001- code: |
|||
| ? | ND077800-1040 | • • TRANSISTOR | 1 | Field_1: TRANSISTOR Field_2: DJE10001- code: |
|||
| ? | ND063600-4580 | • • SERVO MOTOR ASSEMBLY | 1 | Field_1: SERVO MOTOR ASSEMBLY Field_2: DJE10001- code: |
|||
| ? | ND116662-8530 | • • SHAFT | 1 | Field_1: SHAFT Field_2: DJE10001- code: |
|||
| ? | ND116782-6720 | • • LEVER | 1 | Field_1: LEVER Field_2: DJE10001- code: |
|||
| ? | ND116740-5000 | • • DOOR ASSEMBLY | 1 | Field_1: DOOR ASSEMBLY Field_2: DJE10001- code: |
|||
| ? | ND949008-0330 | • • SCREW, TAPPING | 3 | Field_1: SCREW, TAPPING Field_2: DJE10001- code: |
|||
| ? | ND077500-5650 | • • THERMISTOR ASSEMBLY | 1 | Field_1: THERMISTOR ASSEMBLY Field_2: DJE10001- code: |
|||
| ? | ND017661-3560 | • • BRACKET | 1 | Field_1: BRACKET Field_2: DJE10001- code: |
|||
| ? | ND949001-1730 | • • SCREW, TAPPING | 11 | Field_1: SCREW, TAPPING Field_2: DJE10001- code: |
|||
| ? | ND146636-7530 | • • PACKING | 1 | Field_1: PACKING Field_2: DJE10001- code: |
|||
| ? | ND146636-7540 | • • PACKING | 1 | Field_1: PACKING Field_2: DJE10001- code: |
|||
| ? | ND146636-7550 | • • PACKING | 1 | Field_1: PACKING Field_2: DJE10001- code: |
