| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 203-03-17221 | OIL COOLER | 1 | Field_1: OIL COOLER Field_2: DJE10001- code: |
|||
| ? | 203-03-17231 | OIL COOLER | 1 | Field_1: OIL COOLER Field_2: DJE10001- code: |
|||
| ? | 07000-13035 | O-RING | 2 | Field_1: O-RING Field_2: DJE10001- code: |
|||
| ? | 01010-81080 | BOLT | 4 | Field_1: BOLT Field_2: DJE10001- code: |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: WASHER Field_2: DJE10001- code: |
|||
| ? | 203-03-12151 | BRACKET | 1 | Field_1: BRACKET Field_2: DJE10001- code: |
|||
| ? | 01010-81025 | BOLT | 4 | Field_1: BOLT Field_2: DJE10001- code: |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: WASHER Field_2: DJE10001- code: |
|||
| ? | 20Y-43-15410 | WASHER | 4 | Field_1: WASHER Field_2: DJE10001- code: |
|||
| ? | 203-03-12540 | SHEET | 1 | Field_1: SHEET Field_2: DJE10001- code: |
|||
| ? | 203-03-71720 | SHEET | 2 | Field_1: SHEET Field_2: DJE10001- code: |
|||
| ? | 203-03-12661 | SHEET | 1 | Field_1: SHEET Field_2: DJE10001- code: |
|||
| ? | 203-03-12671 | SHEET | 2 | Field_1: SHEET Field_2: DJE10001- code: |
|||
| ? | 203-03-12681 | SHEET | 1 | Field_1: SHEET Field_2: DJE10001- code: |
|||
| ? | 01010-81025 | BOLT | 3 | Field_1: BOLT Field_2: DJE10001- code: |
|||
| ? | 01643-31032 | WASHER | 3 | Field_1: WASHER Field_2: DJE10001- code: |
|||
| ? | 203-03-12420 | NET | 1 | Field_1: NET Field_2: DJE10001- code: |
|||
| ? | 203-03-12411 | NET | 1 | Field_1: NET Field_2: DJE10001- code: |
|||
| ? | 01434-10616 | BOLT, WING | 4 | Field_1: BOLT, WING Field_2: DJE10001- code: |
|||
| ? | 203-03-17111 | SHROUD | 1 | Field_1: SHROUD Field_2: DJE10001- code: |
|||
| ? | 01435-00820 | BOLT | 8 | Field_1: BOLT Field_2: DJE10001- code: |
|||
| ? | 203-03-12371 | COVER ASSEMBLY | 1 | Field_1: COVER ASSEMBLY Field_2: DJE10001- code: |
|||
| ? | • COVER | 1 | Field_1: COVER Field_2: DJE10001- code: C1 |
||||
| ? | 203-03-71730 | • SHEET | 1 | Field_1: SHEET Field_2: DJE10001- code: |
|||
| ? | 203-03-71740 | • SHEET | 1 | Field_1: SHEET Field_2: DJE10001- code: |
|||
| ? | 01010-81020 | BOLT | 3 | Field_1: BOLT Field_2: DJE10001- code: |
|||
| ? | 01643-31032 | WASHER | 3 | Field_1: WASHER Field_2: DJE10001- code: |
|||
| ? | 203-03-17240 | COVER ASSEMBLY | 1 | Field_1: COVER ASSEMBLY Field_2: DJE10001- code: |
|||
| ? | • COVER | 1 | Field_1: COVER Field_2: DJE10001- code: C1 |
||||
| ? | 203-03-71750 | • SHEET | 1 | Field_1: SHEET Field_2: DJE10001- code: |
|||
| ? | 01010-81020 | BOLT | 2 | Field_1: BOLT Field_2: DJE10001- code: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: WASHER Field_2: DJE10001- code: |
