| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 201-60-81112 | TANK | 1 | Field_1: TANK Field_2: DJA20001- code: |
|||
| ? | 22P-60-21170 | FILLER NECK | 1 | Field_1: FILLER NECK Field_2: DJA20001- code: |
|||
| ? | 20Y-60-21340 | GASKET | 1 | Field_1: GASKET Field_2: DJA20001- code: |
|||
| ? | 01252-70516 | BOLT | 6 | Field_1: BOLT Field_2: DJA20001- code: |
|||
| ? | 01601-20513 | WASHER | 6 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 21W-60-41170 | VALVE ASS'Y | 1 | Field_1: VALVE ASS'Y Field_2: DJA20001- code: |
|||
| ? | 20X-60-22140 | SPRING | 1 | Field_1: SPRING Field_2: DJA20001- code: |
|||
| ? | 22P-60-21161 | ELEMENT | 1 | Field_1: ELEMENT Field_2: DJA20001- code: |
|||
| ? | 201-60-81160 | COVER | 1 | Field_1: COVER Field_2: DJA20001- code: |
|||
| ? | 07000-12135 | O-RING | 1 | Field_1: O-RING Field_2: DJA20001- code: |
|||
| ? | 01010-81025 | BOLT | 3 | Field_1: BOLT Field_2: DJA20001- code: |
|||
| ? | 01643-31032 | WASHER | 3 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 201-60-81170 | HOSE | 1 | Field_1: HOSE Field_2: DJA20001- code: |
|||
| ? | 07285-00125 | CLIP | 1 | Field_1: CLIP Field_2: DJA20001- code: |
|||
| ? | 201-60-81151 | CAP | 1 | Field_1: CAP Field_2: DJA20001- code: |
|||
| ? | 423-60-35460 | • ELEMENT | 1 | Field_1: ELEMENT Field_2: DJA20001- code: |
|||
| ? | 201-60-81220 | COVER | 1 | Field_1: COVER Field_2: DJA20001- code: |
|||
| ? | 07000-12145 | O-RING | 1 | Field_1: O-RING Field_2: DJA20001- code: |
|||
| ? | 01010-81035 | BOLT | 4 | Field_1: BOLT Field_2: DJA20001- code: |
|||
| ? | 01643-31032 | WASHER | 4 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 12R-60-11230 | SPRING | 1 | Field_1: SPRING Field_2: DJA20001- code: |
|||
| ? | 201-60-81121 | ROD | 1 | Field_1: ROD Field_2: DJA20001- code: |
|||
| ? | 21W-60-41150 | STRAINER ASS'Y | 1 | Field_1: STRAINER ASS'Y Field_2: DJA20001- code: |
|||
| ? | 07044-12412 | PLUG | 1 | Field_1: PLUG Field_2: DJA20001- code: |
|||
| ? | 07002-12434 | O-RING | 1 | Field_1: O-RING Field_2: DJA20001- code: |
|||
| ? | 201-60-65240 | TUBE | 1 | Field_1: TUBE Field_2: DJA20001- code: |
|||
| ? | 203-60-31100 | ELBOW ASS'Y | 2 | Field_1: ELBOW ASS'Y Field_2: DJA20001- code: |
|||
| ? | 203-60-31230 | ELBOW | 2 | Field_1: ELBOW Field_2: DJA20001- code: |
|||
| ? | 203-60-31240 | NUT | 2 | Field_1: NUT Field_2: DJA20001- code: |
|||
| ? | 203-60-31250 | SLEEVE | 2 | Field_1: SLEEVE Field_2: DJA20001- code: |
|||
| ? | 01010-81230 | BOLT | 4 | Field_1: BOLT Field_2: DJA20001- code: |
|||
| ? | 01643-31232 | WASHER | 4 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 198-60-55510 | BREATHER | 1 | Field_1: BREATHER Field_2: DJA20001- code: |
