| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (702-16-01270) | PILOT VALVE | 1 | Field_1: PILOT VALVE Field_2: DJA20001- code: |
|||
| ? | 22U-54-25660 | SEAL | 1 | Field_1: SEAL Field_2: DJA20001- code: |
|||
| ? | 22U-43-21470 | SEAT | 1 | Field_1: SEAT Field_2: DJA20001- code: |
|||
| ? | 01010-81030 | BOLT | 2 | Field_1: BOLT Field_2: DJA20001- code: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 20Y-62-25360 | BRACKET | 1 | Field_1: BRACKET Field_2: DJA20001- code: |
|||
| ? | 01010-81035 | BOLT | 2 | Field_1: BOLT Field_2: DJA20001- code: |
|||
| ? | 01643-31032 | WASHER | 2 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 201-54-83560 | PEDAL | 1 | Field_1: PEDAL Field_2: DJA20001- code: |
|||
| ? | 01010-D1045 | BOLT | 2 | Field_1: BOLT Field_2: DJA20001- code: |
|||
| ? | 01643-71032 | WASHER | 2 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 201-54-83551 | PEDAL | 1 | Field_1: PEDAL Field_2: DJA20001- code: |
|||
| ? | 01010-81020 | BOLT | 3 | Field_1: BOLT Field_2: DJA20001- code: |
|||
| ? | 01643-31032 | WASHER | 3 | Field_1: WASHER Field_2: DJA20001- code: |
|||
| ? | 207-43-81240 | CAP | 1 | Field_1: CAP Field_2: DJA20001- code: |
|||
| ? | 20T-910-8660 | NIPPLE | 1 | Field_1: NIPPLE Field_2: DJA20001- code: |
|||
| ? | 07000-12011 | O-RING | 1 | Field_1: O-RING Field_2: DJA20001- code: |
|||
| ? | 21W-62-43980 | ELBOW | 2 | Field_1: ELBOW Field_2: DJA20001- code: |
|||
| ? | 02896-11008 | O-RING | 2 | Field_1: O-RING Field_2: DJA20001- code: |
|||
| ? | 07000-12011 | O-RING | 2 | Field_1: O-RING Field_2: DJA20001- code: |
|||
| ? | 21W-62-41780 | NIPPLE | 1 | Field_1: NIPPLE Field_2: DJA20001- code: |
|||
| ? | 02896-11008 | O-RING | 1 | Field_1: O-RING Field_2: DJA20001- code: |
|||
| ? | 11Y-62-12140 | NIPPLE | 1 | Field_1: NIPPLE Field_2: DJA20001- code: |
|||
| ? | 02896-11008 | O-RING | 1 | Field_1: O-RING Field_2: DJA20001- code: |
|||
| ? | 07000-12011 | O-RING | 2 | Field_1: O-RING Field_2: DJA20001- code: |
