| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 704-00110A | BUCKET ASS'Y-2.87§© | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: GODET LNKOP: IP: |
|||
| ? | 704-00111A | BUCKET SUB ASS'Y | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: GODET LNKOP: IP: |
|||
| ? | - | . BUCKET;WELD | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: . GODET LNKOP: IP: |
|||
| ? | 2713-1273 | .. ADAPTER;TOOTH | 6 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: .. DENT DE ADAPTEUR LNKOP: IP: |
|||
| ? | 2110-1413 | .. BUSH | 4 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: .. DOUILLE LNKOP: IP: |
|||
| ? | 713-00028 | . POINT;TOOTH | 6 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . DENT LNKOP: IP: |
|||
| ? | 2705-1034 | . PIN;LOCKING | 6 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . BROUCHE LNKOP: IP: |
|||
| ? | 2114-1931 | . WASHER;LOCKING | 6 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . RONDELLE PLATE LNKOP: IP: |
|||
| ? | 2713-1240 | CUTTER;SIDE(R.H) | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COUTEAU LATERAL LNKOP: IP: |
|||
| ? | 2713-1241 | CUTTER;SIDE(L.H) | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COUTEAU LATERAL LNKOP: IP: |
|||
| ? | S0575061 | BOLT M24X3.0X85 | 12 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON A 6 PANS LNKOP: IP: |
|||
| ? | S4013333 | NUT M24X3.0 | 12 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: ECROU LNKOP: IP: |
|||
| ? | 2114-1831 | WASHER;HARDEN M24 | 12 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RONDELLE ELASTIQUE LNKOP: IP: |
