| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 2704-1684 | BUCKET ASS'Y-1.31§©(H.D) | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: GODET LNKOP: IP: |
|||
| ? | 2704-1685 | BUCKET SUB ASS'Y-1.31§© | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: GODET LNKOP: IP: |
|||
| ? | - | . BUCKET;WELD | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: . GODET LNKOP: IP: |
|||
| ? | 2713-6078 | .. ADAPTER;TOOTH | 7 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: .. DENT DE ADAPTEUR LNKOP: IP: |
|||
| ? | 2713-9061 | . POINT;TOOTH | 7 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . DENT LNKOP: IP: |
|||
| ? | 2705-6034 | . PIN;LOCKING | 7 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . GOUPILLE DE BLOCAGE LNKOP: IP: |
|||
| ? | 2705-6033 | . PIN;RUBBER | 7 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . GOUPILLE LNKOP: IP: |
|||
| ? | 2713-1059A | CUTTER;SIDE(R.H) | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COIN DE GODET DROIT LNKOP: IP: |
|||
| ? | 2713-1060A | CUTTER;SIDE(L.H) | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COIN DE GODET GAUCHE LNKOP: IP: |
|||
| ? | S0574861 | BOLT M24X3.0X75 | 10 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON A 6 PANS LNKOP: IP: |
|||
| ? | S4013333 | NUT M24X3.0 | 10 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: ECROU LNKOP: IP: |
|||
| ? | 2114-1831 | WASHER;HARDEN | 10 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RONDELLE ELASTIQUE LNKOP: IP: |
