Содержание Other: DOOSAN-DAEWOO SOLAR 160W-V(S160W-V)
ELECTRIC PARTS(8)-LAMP PART(1820 : 1820)
Номер на схеме Каталожный номер Название Количество Детали
? 500-00198A ELECTRIC PARTS A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 2534-1167A LAMP;FRONT COMBI (RH) 1
SERIAL: 1001-3522
SERIAL_NO: 1001~3522
ICA: I
REP_PNO: 2534-1167B
REP_QTY: 1
SC:
desc: LAMPE
LNKOP:
IP:
? 2534-1167B LAMP;FRONT COMBI (RH) 1
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: LAMPE
LNKOP:
IP:
? 2515-1022D1 . BULB;HALOGEN 24V 70/75W 1
SERIAL: 1001-3522
SERIAL_NO: 1001~3522
ICA: I
REP_PNO: 515-00006
REP_QTY: 1
SC:
desc: . AMPOULE
LNKOP:
IP:
? 515-00006 . BULB;HALOGEN 24V 70/75W 1
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? S861203H . BULB 24V 3W 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? 2534-1163A . LAMP;TURN SIGNAL 24V 21W 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . LAMPE
LNKOP:
IP:
? S3450983 SCREW M6X1.0X20 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? S5102303 WASHER;SPRING M6 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? 2534-1168A LAMP;FRONT COMBI (LH) 1
SERIAL: 1001-3522
SERIAL_NO: 1001~3522
ICA: I
REP_PNO: 2534-1168B
REP_QTY: 1
SC:
desc: LAMPE
LNKOP:
IP:
? 2534-1168B LAMP;FRONT COMBI (LH) 1
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: LAMPE
LNKOP:
IP:
? 2515-1022D1 . BULB;HALOGEN 24V 70/75W 1
SERIAL: 1001-3522
SERIAL_NO: 1001~3522
ICA: I
REP_PNO: 515-00006
REP_QTY: 1
SC:
desc: . AMPOULE
LNKOP:
IP:
? 515-00006 . BULB;HALOGEN 24V 70/75W 1
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? S861203H . BULB 24V 3W 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? 2534-1163A . LAMP;TURN SIGNAL 24V 21W 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . LAMPE
LNKOP:
IP:
? S3450983 SCREW M6X1.0X20 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? S3451003 SCREW M6X1.0X30 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? S5102303 WASHER;SPRING M6 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S4012333 NUT M6X1.0 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? 2114-1058D52 WASHER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? 2534-9069 LAMP;TURN SIGNAL 24V 5W 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: LAMPE
LNKOP:
IP:
? 2515-1021D5 . BULB 24V 5W 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? 2534-1158C LAMP;REAR COMBI (RH) 1
SERIAL: 1001-3522
SERIAL_NO: 1001~3522
ICA: I
REP_PNO: K1014887
REP_QTY: 1
SC:
desc: LAMPE
LNKOP:
IP:
? K1014887 LAMP;REAR COMBI (RH) 1
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: LAMPE
LNKOP:
IP:
? 2534-6029 . CASE;LAMP(R.H) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . CARTER DE LAMPE
LNKOP:
IP:
? S864221H . BULB 24V 21W 2
SERIAL: 1001-3522
SERIAL_NO: 1001~3522
ICA: I
REP_PNO: 515-00015
REP_QTY: 2
SC:
desc: . AMPOULE
LNKOP:
IP:
? 515-00015 . BULB 24V 21W 2
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? S863210H . BULB 24V 10W 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? S863212H . BULB 24V 12W 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? 2534-1159C LAMP;REAR COMBI (LH) 1
SERIAL: 1001-3522
SERIAL_NO: 1001~3522
ICA: I
REP_PNO: K1014888
REP_QTY: 1
SC:
desc: LAMPE
LNKOP:
IP:
? K1014888 LAMP;REAR COMBI (LH) 1
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: LAMPE
LNKOP:
IP:
? 2534-6028 . CASE;LAMP(L.H) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . CARTER DE LAMPE
LNKOP:
IP:
? S864221H . BULB 24V 21W 2
SERIAL: 1001-3522
SERIAL_NO: 1001~3522
ICA: I
REP_PNO: 515-00015
REP_QTY: 2
SC:
desc: . AMPOULE
LNKOP:
IP:
? 515-00015 . BULB 24V 21W 2
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? S863210H . BULB 24V 10W 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? S863212H . BULB 24V 12W 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? 2534-1139A LAMP;LICENCE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: LAMPE
LNKOP:
IP:
? 2515-1021D5 . BULB 24V 5W 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? 534-00044 LAMP;WORKING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: LAMPE
LNKOP:
IP:
? 2515-1022D1 . BULB;HALOGEN 24V 75/70W 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
