Содержание Other: DOOSAN-DAEWOO SOLAR 160W-V(S160W-V)
ELECTRIC PARTS(1)-GAUGE & SWITCH PANEL(1750 : 1750)
Номер на схеме Каталожный номер Название Количество Детали
? 500-00197 ELECTRIC PARTS A/R
SERIAL: 1001-1705
SERIAL_NO: 1001~1705
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 500-00197A ELECTRIC PARTS A/R
SERIAL: 1706-2063
SERIAL_NO: 1706~2063
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 500-00197B ELECTRIC PARTS A/R
SERIAL: 2064-2083
SERIAL_NO: 2064~2083
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 500-00197C ELECTRIC PARTS A/R
SERIAL: 2084-2180
SERIAL_NO: 2084~2180
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 500-00197E ELECTRIC PARTS A/R
SERIAL: 2181-2619
SERIAL_NO: 2181~2619
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 500-00197G ELECTRIC PARTS A/R
SERIAL: 2620-2664
SERIAL_NO: 2620~2664
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 500-00197H ELECTRIC PARTS A/R
SERIAL: 2665-2974
SERIAL_NO: 2665~2974
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 500-00197I ELECTRIC PARTS A/R
SERIAL: 2975-3198
SERIAL_NO: 2975~3198
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 500-00197J ELECTRIC PARTS A/R
SERIAL: 3199-
SERIAL_NO: 3199~
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: EQUIPMENT ELECTRIQUE
LNKOP:
IP:
? 539-00048C PANEL;LCD GAUGE 1
SERIAL: 1001-2619
SERIAL_NO: 1001~2619
ICA: I
REP_PNO: 539-00048E
REP_QTY: 1
SC:
desc: PANNEAU
LNKOP:
IP:
? 539-00048E PANEL;LCD GAUGE 1
SERIAL: 2620-
SERIAL_NO: 2620~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PANNEAU
LNKOP:
IP:
? 159-00195 . SHEET;SWITCH 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . FEUILLE
LNKOP:
IP:
? 515-00012A . BULB 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . AMPOULE
LNKOP:
IP:
? S3450853 SCREW M5X0.8X16 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? S5100203 WASHER;SPRING 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S5000213 WASHER;PLAIN 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
IP:
? 2549-9109 SWITCH;LAMP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INTERRUPTEUR
LNKOP:
IP:
? K9000353 . LAMP;PILOT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . LAMPE
LNKOP:
IP:
? 2549-9098 SWITCH;WORKING LAMP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INTERRUPTEUR
LNKOP:
IP:
? K9000353 . LAMP;PILOT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . LAMPE
LNKOP:
IP:
? 2549-9098 SWITCH;PARKING LAMP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INTERRUPTEUR
LNKOP:
IP:
? K9000353 . LAMP;PILOT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . LAMPE
LNKOP:
IP:
? 2549-9098 SWITCH;RAM LOCK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INTERRUPTEUR
LNKOP:
IP:
? K9000353 . LAMP;PILOT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . LAMPE
LNKOP:
IP:
? 2549-9098 SWITCH;CAR STEREO 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INTERRUPTEUR
LNKOP:
IP:
? K9000353 . LAMP;PILOT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . LAMPE
LNKOP:
IP:
? 2190-2036D24 INSERT;LAMP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INSERTION
LNKOP:
IP:
? 2190-2036D5 INSERT;WORKING LAMP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INSERTION
LNKOP:
IP:
? 2190-2036D16 INSERT;PARKING LAMP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INSERTION
LNKOP:
IP:
? 2190-2584D17 INSERT;RAM LOCK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INSERTION
LNKOP:
IP:
? 2190-2036D23 INSERT;CAR STEREO 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INSERTION
LNKOP:
IP:
? 2528-9040 METER;HOUR 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: METRE D'HEURE
LNKOP:
IP:
? 545-00001 LIGHTER;CIGAR 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ALLUMEUR DE CIGARE
LNKOP:
IP:
? 530-00279 HARNESS;GAUGE PANEL JOINT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: HARNAIS
LNKOP:
IP:
? 530-00274A HARNESS;SWITCH BOX 1
SERIAL: 1001-1705
SERIAL_NO: 1001~1705
ICA:
REP_PNO:
REP_QTY:
SC:
desc: HARNAIS
LNKOP:
IP:
? 530-00274B HARNESS;SWITCH BOX 1
SERIAL: 1706-
SERIAL_NO: 1706~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: HARNAIS
LNKOP:
IP:
