Содержание Other: DOOSAN-DAEWOO SOLAR 160W-V(S160W-V)
BRAKE PIPING(2)(1430 : 1430)
Наименование Страница Код страницы
BRAKE SUPPLY VALVE 4320 4320

Номер на схеме Каталожный номер Название Количество Детали
? 400-01227 BRAKE PIPING A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: CONDUITES DE FREIN
LNKOP:
IP:
? 2420-9325A VALVE;BRAKE SUPPLY 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VANNE
LNKOP:
IP: O
 4320
? S5102603 WASHER;SPRING M10 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S0559353 BOLT M10X1.5X90 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 2197-1552B BRACKET 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT
LNKOP:
IP:
? S0511853 BOLT M10X1.5X20 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S8000111 O-RING 1/4 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2181-2180 ADAPTER PFO1/4-PF1/4 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ADAPTEUR
LNKOP:
IP:
? S8180211 PACKING PF1/4 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: EMBALLAGE
LNKOP:
IP:
? 2549-9093 SWITCH;LOW PRESSURE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INTERRUPTEUR
LNKOP:
IP:
? S8000181 O-RING 7
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2181-1126D23 ADAPTER PFO1/2-PF3/8 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ADAPTEUR
LNKOP:
IP:
? 2181-1126D6 ADAPTER PFO1/2-PF1/2 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ADAPTEUR
LNKOP:
IP:
? S8000141 O-RING P14 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2460-9055 ACCUMULATOR 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ACCUMULATEUR
LNKOP:
IP:
? 181-00524 REDUCER 2-PFO3/8 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: REDUCTEUR
LNKOP:
IP:
? S5102703 WASHER;SPRING M12 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S0515953 BOLT M12X1.75X22 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 195-02381 BRACKET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT
LNKOP:
IP:
? 471-00024A FILTER;BRAKE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: FILTRE
LNKOP:
IP:
? - . HEAD 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: . CULLASSE
LNKOP:
IP:
? - . HOUSING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: . CARTER
LNKOP:
IP:
? 474-00009 . ELEMENT;PILOT FILTER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . ELEMENT FILTRANT
LNKOP:
IP:
? 426-00059 . VALVE;BY-PASS 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . VANNE
LNKOP:
IP:
? 471-00026 . INDICATOR 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . INDICATEUR
LNKOP:
IP:
? PF1116-0002 . O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . JOINT TORIQUE
LNKOP:
IP:
? PF1116-0001 . RING;BACK UP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BAGUE DE SOUTIEN
LNKOP:
IP:
? 530-00097 . HARNESS;PILOT FILTER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . FAISCEAU
LNKOP:
IP:
? S5102303 WASHER;SPRING M6 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S0553753 BOLT M6X1.0X55 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 121-00010D1 NUT PF3/8 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? S8040101 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2181-1126D3 ADAPTER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ADAPTEUR
LNKOP:
IP:
? 2184-1036D256 HOSE PF3/8-650L 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 2184-1026D388 HOSE PF1/2-2200L 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 2184-1096D146 HOSE PF1/2-1080L 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 2184-1036D51 HOSE PF1/2-2500L 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 2181-1951D8 TEE PFO1/2-PF1/2-PF1/4 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TE
LNKOP:
IP:
? S5111001 WASHER;SPRING M18 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
