Содержание Other: DOOSAN-DAEWOO SOLAR 160W-V(S160W-V)
OIL TANK(1180 : 1180)
Номер на схеме Каталожный номер Название Количество Детали
? 470-00143A OIL TANK ASS'Y A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESERVOIR D'HUILE
LNKOP:
IP:
? 470-00145A TANK;OIL 1
SERIAL: 1001-1030
SERIAL_NO: 1001~1030
ICA: I
REP_PNO: 470-00145B
REP_QTY: 1
SC:
desc: RESERVOIR D'HUILE
LNKOP:
IP:
? 470-00145B TANK;OIL 1
SERIAL: 1031-3522
SERIAL_NO: 1031~3522
ICA: I
REP_PNO: 470-00145C
REP_QTY: 1
SC:
desc: RESERVOIR D'HUILE
LNKOP:
IP:
? 470-00145C TANK;OIL 1
SERIAL: 3523-
SERIAL_NO: 3523~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESERVOIR D'HUILE
LNKOP:
IP:
? S0521351 BOLT M16X2.0X35 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 2114-1813 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 2114-1814 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 2473-1076 COVER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? S8011450 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2129-1222 SPRING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESSORT
LNKOP:
IP:
? 2426-9009 VALVE;BY-PASS 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE CLAPET
LNKOP:
IP:
? 2474-9003B ELEMENT;FILTER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ELEMENT FILTRANT
LNKOP:
IP:
? S0512053 BOLT M10X1.5X25 18
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S5102603 WASHER;SPRING M10 18
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? 2473-1088B COVER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? S8011650 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2136-1434 ROD 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TIGE
LNKOP:
IP:
? 2129-1008 SPRING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESSORT
LNKOP:
IP:
? 2140-1183 PIPE;SUCTION 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU
LNKOP:
IP:
? 2474-9016A FILTER;SUCTION 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ELEMENT FILTRANT
LNKOP:
IP:
? 2181-1950D7 PLUG 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? S8000181 O-RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2119-1007 GAUGE;LEVEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JAUGE D'HUILE
LNKOP:
IP:
? 422-00027A BREATHER;AIR 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RENIFLARD
LNKOP:
IP:
? 180-00200 . PACKING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . JOINT
LNKOP:
IP:
? S8011200 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2181-1950D1 PLUG 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? 2114-1816 WASHER;HARD 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? 2181-2667 PLUG 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BONCHON
LNKOP:
IP:
? S8180221 RING;SEAL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE D'ETANCHEITE
LNKOP:
IP:
? S4012733 NUT M12X1.75 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? S2202761 BOLT;SOCKET M5X0.8X8 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? S8000111 O-RING 1/4 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:

Other: DOOSAN-DAEWOO / SOLAR 160W-V(S160W-V) / OIL TANK(1180 : 1180)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
