Содержание Other: DOOSAN-DAEWOO SOLAR 160W-V(S160W-V)
FUEL TANK(1170 : 1170)
Номер на схеме Каталожный номер Название Количество Детали
? 470-00153 FUEL TANK ASS'Y A/R
SERIAL: 1001-1030
SERIAL_NO: 1001~1030
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 470-00153A FUEL TANK ASS'Y A/R
SERIAL: 1031-
SERIAL_NO: 1031~
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 470-00152 TANK;FUEL 1
SERIAL: 1001-1030
SERIAL_NO: 1001~1030
ICA: I
REP_PNO: 470-00152A
REP_QTY: 1
SC:
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 470-00152A TANK;FUEL 1
SERIAL: 1031-1947
SERIAL_NO: 1031~1947
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 470-00152B TANK;FUEL 1
SERIAL: 1948-2083
SERIAL_NO: 1948~2083
ICA: I
REP_PNO: 470-00152C
REP_QTY: 1
SC:
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 470-00152C TANK;FUEL 1
SERIAL: 2084-
SERIAL_NO: 2084~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? S8011650 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 2473-1033B COVER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? S0512053 BOLT M10X1.5X25 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S5102603 WASHER;SPRING M10 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? 2186-9001 COCK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ROBINET
LNKOP:
IP:
? S0521351 BOLT M16X2.0X35 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 2114-1813 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 2114-1814 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 2471-9046 FILTER;FUEL 1
SERIAL: 1001-2519
SERIAL_NO: 1001~2519
ICA: I
REP_PNO: 471-00105
REP_QTY: 1
SC:
desc: FILTRE
LNKOP:
IP:
? 471-00105 FILTER;FUEL 1
SERIAL: 2520-
SERIAL_NO: 2520~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: FILTRE
LNKOP:
IP:
? 2188-9008 CAP 1
SERIAL: 1001-2083
SERIAL_NO: 1001~2083
ICA: I
REP_PNO: 188-00018
REP_QTY: 1
SC:
desc: CHAPEAU
LNKOP:
IP:
? 188-00018 CAP 1
SERIAL: 2084-2599
SERIAL_NO: 2084~2599
ICA: I
REP_PNO: 188-00014A
REP_QTY: 1
SC:
desc: CHAPEAU
LNKOP:
IP:
? 188-00014A CAP 1
SERIAL: 2600-3198
SERIAL_NO: 2600~3198
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CHAPEAU
LNKOP:
IP:
? K1004166 CAP 1
SERIAL: 3199-
SERIAL_NO: 3199~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CHAPEAU
LNKOP:
IP:
? 2181-1950D1 PLUG 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? 119-00014D1 GAUGE;LEVEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JAUGE DE NIVEAU
LNKOP:
IP:
? S8450012 CLAMP;HOSE 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: FIXATION DE TUYAU
LNKOP:
IP:
? 2185-1247D25 HOSE 1
SERIAL: 1031-
SERIAL_NO: 1031~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 2185-1247D25 HOSE;FUEL 2
SERIAL: 1001-1030
SERIAL_NO: 1001~1030
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 2185-1247D34 HOSE;FUEL 1
SERIAL: 1031-2877
SERIAL_NO: 1031~2877
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 2185-1247D130 HOSE;FUEL 3700mm 1
SERIAL: 2878-
SERIAL_NO: 2878~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 2181-1950D7 PLUG 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? S8000231 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 124-00208D3 CLIP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CLIP
LNKOP:
IP:
? 120-00276 BOLT M8X1.25X12 4
SERIAL: 1001-1030
SERIAL_NO: 1001~1030
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 120-00276 BOLT M8X1.25X12 6
SERIAL: 1031-
SERIAL_NO: 1031~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 2114-1816 WASHER;HARD 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? S0514653 BOLT M12X1.75X25 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 2184-9089 HOSE;VINYL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? S8450006 CLAMP;HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: FIXATION DE TUYAU
LNKOP:
IP:
? 2185-1247D33 HOSE;FUEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? 124-00209D1 CLIP 3
SERIAL: 1001-1030
SERIAL_NO: 1001~1030
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CLIP
LNKOP:
IP:
? 2124-1509D7 CLIP 4
SERIAL: 1031-
SERIAL_NO: 1031~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CLIP
LNKOP:
IP:
? 471-00082 SEPARATOR;WATER 1
SERIAL: 1001-2940
SERIAL_NO: 1001~2940
ICA: I
REP_PNO: 471-00082A
REP_QTY: 1
SC:
desc: SEPARATEUR
LNKOP:
IP:
? 471-00082A SEPARATOR;WATER 1
SERIAL: 2941-
SERIAL_NO: 2941~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SEPARATEUR
LNKOP:
IP:
? S0552953 BOLT M6X1.0X22 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S5102303 WASHER;SPRING M6 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? 2114-1058D52 WASHER 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? S8000111 O-RING 1/4 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 120-00276 BOLT M8X1.25X14 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? DS2802021 CLIP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CLIP
LNKOP:
IP:
? 161-00558 SPONGE 1
SERIAL: 1031-
SERIAL_NO: 1031~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: EPONGE
LNKOP:
IP:
? 161-00559 SPONGE 2
SERIAL: 1031-
SERIAL_NO: 1031~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: EPONGE
LNKOP:
IP:
