Содержание Other: DOOSAN-DAEWOO SOLAR 160W-V(S160W-V)
PLANET GEAR-FRONT AXLE(4590 : 4590)
Номер на схеме Каталожный номер Название Количество Детали
? 006.03.0197 NUT 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? 016.13.3271 BOLT 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? 212.06.020.04 CASE;AXLE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CORPS D'ESSIEU
LNKOP:
IP:
? 016.03.3195 BOLT 32
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? 011.17.2952 WASHER 32
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? 212.06.700.01 BUSHING;REDUCTION 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: MANCHON DE REDUCTION
LNKOP:
IP:
? 729.06.009.01 SEAL 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT D'ETANCHEITE
LNKOP:
IP:
? 005.01.0121 BEARING;BALL 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ROULEMENT A BILLES
LNKOP:
IP:
? 002.01.0078 CIRCLIP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARRETOIR
LNKOP:
IP:
? 001.05.1389 O-RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? 212.06.610.03 JOINT 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT
LNKOP:
IP:
? 277.06.005.01 BUSHING;THRUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? 212.06.023.02 BUSHING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? 112.04.022.01 BOLT 24
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? 212.06.007.03 COVER 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? 008.02.0214 FITTING;GREASE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GRAISSEUR
LNKOP:
IP:
? 212.06.701.04 PIN;PIVOT 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PIVOT DE DIRECTION
LNKOP:
IP:
? 212.06.701.03 PIN;PIVOT 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PIVOT DE DIRECTION
LNKOP:
IP:
? 001.39.3270 SEAL 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT D'ETANCHEITE
LNKOP:
IP:
? 290.06.016.01 BEARING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ROULEMENT
LNKOP:
IP:
? 212.06.021.03 CASE;STEERING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOITIER DE DIRECTION
LNKOP:
IP:
? 212.06.051.01 SEAL 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT D'ETANCHEITE
LNKOP:
IP:
? 112.01.610.02 PLUG;MAGNET 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON MAGNETIQUE
LNKOP:
IP:
? 112.01.610.01 PLUG 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? 212.06.022.03 CASE;STEERING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOITIER DE DIRECTION
LNKOP:
IP:
? 001.21.2743 SEAL 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT D'ETANCHEITE
LNKOP:
IP:
? 005.10.2742 BEARING 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ROULEMENT
LNKOP:
IP:
? 176.06.006.01 STUD;WHEEL 16
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GOUJON DE ROUE
LNKOP:
IP:
? 112.06.053.01 HUB;WHEEL 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: MOYEU DE ROUE
LNKOP:
IP:
? 176.07.029.01 O-RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT OR
LNKOP:
IP:
? 112.06.005.04 GEAR;RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COURONNE DENTEE
LNKOP:
IP:
? 112.06.007.07 SUPPORT;RING GEAR 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT PORTE COURONNE
LNKOP:
IP:
? 002.14.3191 CIRCLIP 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARRETOIR
LNKOP:
IP:
? 112.06.006.03 GEAR;PLANET 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SATELLITE
LNKOP:
IP:
? 112.06.008.02 BEARING 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ROULEMENT
LNKOP:
IP:
? 006.11.1413 NUT 20
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? 016.06.0442 BOLT;COUNTERSUNK 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS A TETE CONIQUE
LNKOP:
IP:
? 112.06.052.02 CARRIER;PLANET GEAR 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT SATELLITES
LNKOP:
IP:
? 112.06.025.01 STUD 16
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GOUJON
LNKOP:
IP:
? 006.04.1159 NUT 16
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? 002.06.3193 CIRCLIP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARRETOIR
LNKOP:
IP:
? 213.06.011.01 BOLT 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? 006.05.1521 NUT 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? 112.06.026.01 PLATE;LOCKING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TOLE DE SECURITE
LNKOP:
IP:
? 002.02.0088 CIRCLIP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARRETOIR
LNKOP:
IP:
? 176.06.006.03 STUD;WHEEL 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GOUJON DE ROUE
LNKOP:
IP:
? 212.06.026.01 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 212.06.026.02 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 212.06.026.03 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 212.06.710.03 CARRIER;PLANET GEAR 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT SATELLITES
LNKOP:
IP:
? 212.06.721.03 CASE;STEERING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOITIER DE DIRECTION
LNKOP:
IP:
? 212.06.722.03 CASE;STEERING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOITIER DE DIRECTION
LNKOP:
IP:

Other: DOOSAN-DAEWOO / SOLAR 160W-V(S160W-V) / PLANET GEAR-FRONT AXLE(4590 : 4590)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
