Содержание Other: DOOSAN-DAEWOO SOLAR 160W-V(S160W-V)
REGULATOR-FRONT(4110 : 4110)
Номер на схеме Каталожный номер Название Количество Детали
? 720944A REGULATOR;FRONT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: REGULATEUR
LNKOP:
IP:
? 200852 BOLT;SOCKET 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? 205526 BOLT;SOCKET 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? 200833 BOLT;SOCKET 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? 200830 BOLT;SOCKET 10
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? 134596 PLUG 5
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? 140783 CASING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: CARTER
LNKOP:
IP:
? 140789 LEVER;FEEDBACK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: LEVIER
LNKOP:
IP:
? 140787 LEVER(1) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: LEVIER
LNKOP:
IP:
? 140788 LEVER(2) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: LEVIER
LNKOP:
IP:
? 140795 PLUG;CENTER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: BOUCHON
LNKOP:
IP:
? 140796 PLUG;ADJUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: BOUCHON
LNKOP:
IP:
? 113413A PISTON;COMPENSATOR 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: PISTON COMPENSATEUR
LNKOP:
IP:
? 113414A CASE;PISTON 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: BOITIER A PISTON
LNKOP:
IP:
? 113415 ROD;COMPENSATOR 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: TIGE DE COMPENSATEUR
LNKOP:
IP:
? 113416 SEAT;SPRING(C) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: SIEGE
LNKOP:
IP:
? 133587 SPRING;OUTER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESSORT
LNKOP:
IP:
? 131657 SPRING;INNER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESSORT INTERIEUR
LNKOP:
IP:
? 120009 STEM;ADJUST(C) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: BOUCHON DE REGLAGE
LNKOP:
IP:
? 120010 SCREW;ADJUST(C) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: VIS
LNKOP:
IP:
? 140785 COVER(C) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: COUVERCLE
LNKOP:
IP:
? 113396 NUT;LOCK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: ECROU
LNKOP:
IP:
? 138816 SLEEVE;PF 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: MANCHON
LNKOP:
IP:
? 115804 COVER;PILOT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: COUVERCLE
LNKOP:
IP:
? 113406 PISTON;PILOT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: PISTON PILOTE
LNKOP:
IP:
? 113431 SEAT;SPRING(Q) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: CUVETTE DE RESSORT
LNKOP:
IP:
? 113437 STEM;ADJUST(Q) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: BAGUE DE REGLAGE
LNKOP:
IP:
? 136486 SPRING;PILOT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESSORT
LNKOP:
IP:
? 113440 SLEEVE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: MANCHON
LNKOP:
IP:
? 140786 SPOOL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: BOBINE
LNKOP:
IP:
? 113442 SEAT;SPRING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: CUVETTE DE RESSORT
LNKOP:
IP:
? 131664 SPRING;RETURN 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESSORT
LNKOP:
IP:
? 131665 SPRING;SET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESSORT
LNKOP:
IP:
? 113445 COVER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: COUVERCLE
LNKOP:
IP:
? 120055 PISTON 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: PISTON
LNKOP:
IP:
? 201673 O-RING 1BG75 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201757 O-RING 1BP6 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201765 O-RING 1BP8 9
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201685 O-RING 1BP10 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201710 O-RING 1BP18 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201718 O-RING 1BP22 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201706 O-RING 1BP16 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201713 O-RING 1BP20 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201654 O-RING 1BP25 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 204458 O-RING 1BP12.5 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201689 O-RING 1BP11 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201723 O-RING 1BP26 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 201660 O-RING 1BG35 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 212035 NUT;HEX. 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU 6 PANS
LNKOP:
IP:
? 204956 RING;SNAP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE D'ARRET
LNKOP:
IP:
? 215018 RING;STOP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: BAGUE D'ARRET
LNKOP:
IP:
? 212036 RING;SNAP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE
LNKOP:
IP:
? 217841 PIN 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: GOUPILLE
LNKOP:
IP:
? 140793 PIN 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: GOUPILLE
LNKOP:
IP:
? 140792 PIN 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: GOUPILLE
LNKOP:
IP:
? 113394 PIN 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: GOUPILLE
LNKOP:
IP:
? 140794 PIN 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: GOUPILLE
LNKOP:
IP:
? 138817 PISTON;PF 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: PISTON
LNKOP:
IP:
? 202523 SCREW;SET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? 113395 SCREW;ADJUST(Q) 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: VIS
LNKOP:
IP:

Other: DOOSAN-DAEWOO / SOLAR 160W-V(S160W-V) / REGULATOR-FRONT(4110 : 4110)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
