| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 500-00079 | ELECTRIC PARTS | A/R | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: ELECTRIQUE LNKOP: IP: |
|||
| ? | S3450833 | SCREW M5X0.8X12 | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | S5100203 | WASHER;SPRING M5 | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RONDELLE ELASTIQUE LNKOP: IP: |
|||
| ? | 161-00260 | RUBBER;TRIM | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: CAOUTCHOUC LNKOP: IP: |
|||
| ? | S3450953 | SCREW M6X1.0X12 | 7 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | S5102303 | WASHER;SPRING M6 | 7 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RONDELLE ELASTIQUE LNKOP: IP: |
|||
| ? | 2160-1004D16 | BUSHING;RUBBER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: MANCHON CAOUTCHOUC LNKOP: IP: |
|||
| ? | 2544-1023 | RELAY;STARTER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: UNITE LNKOP: IP: |
|||
| ? | 2544-1023 | RELAY;PREHEATER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: UNITE LNKOP: IP: |
|||
| ? | 2527-9004 | BREAKER;CIRCUIT | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: SUPPORT LNKOP: IP: |
|||
| ? | 2120-1354 | SCREW | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | 195-01341 | BRACKET;CIRCUIT BREAKER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: SUPPORT LNKOP: IP: |
|||
| ? | 537-00030 | TIMER;PREHEATER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: INTERRUPTEUR LNKOP: IP: |
|||
| ? | 2544-9032 | RELAY;WORKING LAMP | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: UNITE LNKOP: IP: |
|||
| ? | 2544-9032 | RELAY;HORN | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: UNITE LNKOP: IP: |
