Содержание Other: DOOSAN-DAEWOO SOLAR 030PLUS (S/N. 20001 ~ )(S030p-c)
FUEL TANK(1200 : 1200)
Номер на схеме Каталожный номер Название Количество Детали
? 470-00094 FUEL TANK A/R
SERIAL: 20001-20575
SERIAL_NO: 20001~20575
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 470-00524 FUEL TANK A/R
SERIAL: 20576-
SERIAL_NO: 20576~
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 2470-2044H TANK;FUEL 1
SERIAL: 20001-20575
SERIAL_NO: 20001~20575
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 470-00523 TANK;FUEL 1
SERIAL: 20576-
SERIAL_NO: 20576~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? S8450006 CLAMP;HOSE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
IP:
? 185-00390 GAUGE;LEVEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INDICATEUR
LNKOP:
IP:
? 2471-9010A STRAINER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: FILTRE
LNKOP:
IP:
? 2188-9007A CAP;TANK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CHAPEAU D'INTERRUPTEUR
LNKOP:
IP:
? 2186-9001 COCK;DRAIN 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ROBINET
LNKOP:
IP:
? S8450006 CLIP;HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
IP:
? 2184-1302 HOSE;VINYL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE PVC
LNKOP:
IP:
? S0512353 BOLT M10X1.5X35 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6PANS
LNKOP:
IP:
? S5102603 WASHER;SPRING M10 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S5010613 WASHER;PLAIN M10 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
IP:
? 2114-1058D10 WASHER M10 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
IP:
? 2114-1300 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 2114-1302 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CALE
LNKOP:
IP:
? 2470-2045C COVER;TANK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? S3457101 SCREW;MACHINE 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? S5010513 WASHER;PLAIN 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:

Other: DOOSAN-DAEWOO / SOLAR 030PLUS (S/N. 20001 ~ )(S030p-c) / FUEL TANK(1200 : 1200)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
