| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 621-02619B | PANEL ASS'Y | A/R | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: PANNEAU LNKOP: IP: |
|||
| ? | 621-02550 | PANEL ASS'Y | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: PANNEAU LNKOP: IP: |
|||
| ? | - | . PANEL;SIDE | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: . PANNEAU LNKOP: IP: |
|||
| ? | 2415-9007 | . NOZZLE;ROUND | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . INJECTEUR LNKOP: IP: |
|||
| ? | S3644213 | . SCREW D3.5X8 | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . VIS LNKOP: IP: |
|||
| ? | 621-01984 | HOLDER;CUP | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: SUPPORT LNKOP: IP: |
|||
| ? | 621-01908 | BOX | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOITE LNKOP: IP: |
|||
| ? | 185-00388 | TUBE;DEFROSTER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUBE LNKOP: IP: |
|||
| ? | S8450023 | CLAMP;HOSE | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COLLIER LNKOP: IP: |
|||
| ? | 2549-9114 | SWITCH;WIPER & WASHER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: INTERRUPTEUR LNKOP: IP: |
|||
| ? | S3452853 | SCREW M5X0.8X16 | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | 2120-2174 | SCRIVET | 6 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RIVET LNKOP: IP: |
|||
| ? | 2190-2036D14 | INSERT;WIPER & WASHER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: INSERTION LNKOP: IP: |
|||
| ? | 530-00353A | HARNESS;CABIN | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: HARNAIS LNKOP: IP: |
