Содержание Other: DOOSAN-DAEWOO SOLAR 130W-III(S130w-3)
HEATER BOX(1570 : 1570)
Номер на схеме Каталожный номер Название Количество Детали
? 2920-1040A BOX;HEATER 1
SERIAL: 1-10
SERIAL_NO: 1~10
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOITE
LNKOP:
? 2920-1040B BOX;HEATER 1
SERIAL: 11-50
SERIAL_NO: 11~50
ICA: P
REP_PNO: 2920-1040C
REP_QTY: 1
SC:
desc: BOITE
LNKOP:
? 2920-1040C BOX;HEATER 1
SERIAL: 51-100
SERIAL_NO: 51~100
ICA: I
REP_PNO: 2920-1040E
REP_QTY: 1
SC:
desc: BOITE
LNKOP:
? 2920-1040E BOX;HEATER 1
SERIAL: 101-653
SERIAL_NO: 101~653
ICA: I
REP_PNO: 2920-1040G
REP_QTY: 1
SC:
desc: BOITE
LNKOP:
? 2920-1040J BOX;HEATER 1
SERIAL: 654-1386
SERIAL_NO: 654~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOITE
LNKOP:
? 2195-3715A SUPPORT 1
SERIAL: 1-50
SERIAL_NO: 1~50
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT
LNKOP:
? 2195-3715B SUPPORT 1
SERIAL: 51-100
SERIAL_NO: 51~100
ICA: P
REP_PNO: 2195-3715E
REP_QTY: 1
SC:
desc: SUPPORT
LNKOP:
? 2195-3715C SUPPORT 1
SERIAL: 101-277
SERIAL_NO: 101~277
ICA: I
REP_PNO: 2195-3715G
REP_QTY: 1
SC:
desc: SUPPORT
LNKOP:
? 2195-3715G SUPPORT 1
SERIAL: 278-1386
SERIAL_NO: 278~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT
LNKOP:
? 2621-2643 COVER 1
SERIAL: 1-10
SERIAL_NO: 1~10
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2643A COVER 1
SERIAL: 11-50
SERIAL_NO: 11~50
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2643B COVER 1
SERIAL: 51-277
SERIAL_NO: 51~277
ICA: I
REP_PNO: 2621-2643C
REP_QTY: 1
SC:
desc: COUVERCLE
LNKOP:
? 2621-2643C COVER 1
SERIAL: 278-1386
SERIAL_NO: 278~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2644 COVER 1
SERIAL: 1-10
SERIAL_NO: 1~10
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2644A COVER 1
SERIAL: 11-50
SERIAL_NO: 11~50
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2644B COVER 1
SERIAL: 51-1386
SERIAL_NO: 51~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2693A COVER 1
SERIAL: 1-10
SERIAL_NO: 1~10
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2693B COVER 1
SERIAL: 11-50
SERIAL_NO: 11~50
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2693C COVER 1
SERIAL: 51-263
SERIAL_NO: 51~263
ICA: I
REP_PNO: 2621-2643E
REP_QTY: 2
SC:
desc: COUVERCLE
LNKOP:
? 2191-3235A PLATE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PLAQUE
LNKOP:
? 2415-9003 NOZZLE;AIRCON 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BUSE
LNKOP:
? S0504453 BOLT M6X1.0X12 12
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
? S0504453 BOLT M6X1.0X12 9
SERIAL: 263-1386
SERIAL_NO: 263~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
? S5000313 WASHER;PLAIN M6 12
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
? S5000313 WASHER;PLAIN M6 9
SERIAL: 263-1386
SERIAL_NO: 263~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
? S0508652 BOLT M8X1.25X16 9
SERIAL_NO:
ICA: Y
REP_PNO: S0508653
REP_QTY: 9
SC:
desc: BOULON A 6 PANS
LNKOP:
? S0508653 BOLT M8X1.25X16 9
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
? S5010511 WASHER;PLAIN M8 9
SERIAL_NO:
ICA: Y
REP_PNO: S5010513
REP_QTY: 9
SC:
desc: RONDELLE PLATE
LNKOP:
? S5010513 WASHER;PLAIN M8 9
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
? 2190-2049 PLATE;NAME 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PLAQUE D'IDENTIFICATION
LNKOP:
? 2621-2774A COVER 1
SERIAL: 1-100
SERIAL_NO: 1~100
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2920 COVER 1
SERIAL: 101-1386
SERIAL_NO: 101~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? 2621-2642A COVER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
? S0504453 BOLT M6X1.0X12 2
SERIAL: 11-100
SERIAL_NO: 11~100
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
? S0504453 BOLT M6X1.0X12 4
SERIAL: 101-1386
SERIAL_NO: 101~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
? S5110301 WASHER;SPRING M6 2
SERIAL: 1-100
SERIAL_NO: 1~100
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
? S5110301 WASHER;SPRING M6 4
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
? S5110303 WASHER;SPRING M6 4
SERIAL: 263-1386
SERIAL_NO: 263~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
? S5020311 WASHER;PLAIN M6 2
SERIAL: 1-100
SERIAL_NO: 1~100
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
? S5020311 WASHER;PLAIN M6 4
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
? S5020313 WASHER;PLAIN M6 4
SERIAL: 263-1386
SERIAL_NO: 263~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
? 2158-1017D1 HOSE 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
? 2158-1017D1 HOSE 5
SERIAL: 101-1386
SERIAL_NO: 101~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
? 2158-1017D1 HOSE 1
SERIAL: 1387-
SERIAL_NO: 1387~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
? S8450044 CLAMP;HOSE 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
? S8450044 CLAMP;HOSE 9
SERIAL: 101-1386
SERIAL_NO: 101~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
? S8450044 CLAMP;HOSE 1
SERIAL: 1387-
SERIAL_NO: 1387~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
? S0511852 BOLT M10X1.5X20 4
SERIAL_NO:
ICA: Y
REP_PNO: S0511853
REP_QTY: 4
SC:
desc: BOULON A 6 PANS
LNKOP:
? S0511853 BOLT M10X1.5X20 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
? S5102601 WASHER;SPRING M10 4
SERIAL_NO:
ICA: Y
REP_PNO: S5102603
REP_QTY: 4
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
? S5102603 WASHER;SPRING M10 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
? S5010611 WASHER;PLAIN M10 4
SERIAL_NO:
ICA: Y
REP_PNO: S5010613
REP_QTY: 4
SC:
desc: RONDELLE PLATE
LNKOP:
? S5010613 WASHER;PLAIN M10 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE PLATE
LNKOP:
? S3644193 SCREW;TAPPING M3 2
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
? 2415-9005 NOZZLE;SPINDLE 1
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BUSE
LNKOP:
? 2125-1081 CASE;UPPER 1
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CARTER
LNKOP:
? 2125-1082 CASE;LOWER 1
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CARTER
LNKOP:
? S3640523 SCREW;TAPPING M5 4
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
? 2161-1953 PLATE 1
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PLAQUE
LNKOP:
? 2124-1084D3 CLIP;BAND 250L 1
SERIAL: 101-
SERIAL_NO: 101~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
? 2161-1744 RUBBER;DF 1
SERIAL: 101-1386
SERIAL_NO: 101~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAOUTCHOUC
LNKOP:
? 2160-1219 GROMMET 1
SERIAL: 278-1386
SERIAL_NO: 278~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GARNISSAGE CAOUTCHOUC
LNKOP:
? 2161-1744 RUBBER;DF 1
SERIAL: 263-1386
SERIAL_NO: 263~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAOUTCHOUC
LNKOP:
? 2161-1744 RUBBER;DF 1
SERIAL: 263-1386
SERIAL_NO: 263~1386
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAOUTCHOUC
LNKOP:
? 2621-3023 COVER 1
SERIAL: 746-
SERIAL_NO: 746~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
