Содержание Other: DOOSAN-DAEWOO SOLAR 150LC-V - DIEU(E150LC-V)
TRACK FRAME(2100 : 2100)
Номер на схеме Каталожный номер Название Количество Детали
? 2604-1267 TRACK ASS'Y A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: TRAIN DE ROULEMENT
LNKOP:
IP:
? 9604-1033A TRACK ASS'Y A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: TRAIN DE ROULEMENT
LNKOP:
IP:
? 9400-1035 TRACK ASS'Y A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: TRAIN DE ROULEMENT
LNKOP:
IP:
? 604-00034A FRAME;TRACK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TRAIN DE ROULEMENT
LNKOP:
IP:
? 109-00028B BEARING;SWING 1
SERIAL: 1-50153
SERIAL_NO: 1~50153
ICA: Y
REP_PNO: 9109-6006
REP_QTY: 1
SC:
desc: PALIER
LNKOP:
IP:
? 9109-6006 BEARING;SWING 1
SERIAL: 50154-50230
SERIAL_NO: 50154~50230
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PALIER
LNKOP:
IP:
? 9109-6009 BEARING;SWING 1
SERIAL: 50231-50250
SERIAL_NO: 50231~50250
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PALIER
LNKOP:
IP:
? 9109-6009A BEARING;SWING 1
SERIAL: 50251-50260
SERIAL_NO: 50251~50260
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PALIER
LNKOP:
IP:
? 9109-6006 BEARING;SWING 1
SERIAL: 50261-
SERIAL_NO: 50261~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PALIER
LNKOP:
IP:
? 180-00297D3 . SEAL 5MM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . JOINT
LNKOP:
IP:
? 2623-4002B GUARD;LINK 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BARRE DE PROTECTION
LNKOP:
IP:
? 2621-1428 COVER 1
SERIAL: 1-50125
SERIAL_NO: 1~50125
ICA: Y
REP_PNO: 2621-1428B
REP_QTY: 1
SC:
desc: CAPOT
LNKOP:
IP:
? 2621-1428B COVER 1
SERIAL: 50126-50230
SERIAL_NO: 50126~50230
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPOT
LNKOP:
IP:
? 2621-1428 COVER 1
SERIAL: 50231-
SERIAL_NO: 50231~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPOT
LNKOP:
IP:
? 2403-1002 COVER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPOT
LNKOP:
IP:
? 2180-1017A PACKING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ETANCHE
LNKOP:
IP:
? 621-00236 COVER 2
SERIAL: 50144-
SERIAL_NO: 50144~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPOT
LNKOP:
IP:
? S5102903 WASHER;SPRING M6 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE GROWER M16
LNKOP:
IP:
? 2114-9012 WASHER 36
SERIAL: 1-50230
SERIAL_NO: 1~50230
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE GROWER
LNKOP:
IP:
? 2114-9012A WASHER 36
SERIAL: 50231-
SERIAL_NO: 50231~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE GROWER
LNKOP:
IP:
? 2120-2196D1 BOLT M10X1.5X20 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 2120-2196D2 BOLT M10X1.5X25 12
SERIAL: 50144-
SERIAL_NO: 50144~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S0721466 BOLT M16X1.5X40 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S0770261 BOLT M20X1.5X70 36
SERIAL: 1-50230
SERIAL_NO: 1~50230
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S0570261 BOLT M20X1.5X70 36
SERIAL: 50231-50250
SERIAL_NO: 50231~50250
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S0770266 BOLT M20X1.5X70 36
SERIAL: 50251-
SERIAL_NO: 50251~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S0712053 BOLT M10X1.5X25 22
SERIAL: 1-50143
SERIAL_NO: 1~50143
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 2114-1058D10 WASHER 22
SERIAL: 1-50143
SERIAL_NO: 1~50143
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? S5102603 WASHER;SPRING 22
SERIAL: 1-50143
SERIAL_NO: 1~50143
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE GROWER
LNKOP:
IP:
? 2621-4125B COVER-L.H 1
SERIAL: 1-50143
SERIAL_NO: 1~50143
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPOT
LNKOP:
IP:
? 2621-4124B COVER-R.H 1
SERIAL: 1-50143
SERIAL_NO: 1~50143
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPOT
LNKOP:
IP:
? 2621-4126B COVER-L.H 1
SERIAL: 1-50143
SERIAL_NO: 1~50143
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPOT
LNKOP:
IP:
? 2621-4127B COVER-R.H 1
SERIAL: 1-50143
SERIAL_NO: 1~50143
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPOT
LNKOP:
IP:
