Содержание Other: DOOSAN-DAEWOO SOLAR 130LC-V - DIEU(E130LC-V)
OIL FILTER(008 : 008)
Номер на схеме Каталожный номер Название Количество Детали
? 65.05501-7065C OIL FILTER ASS'Y 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: FILTRE A GAZOLE
LNKOP:
IP:
? 65.05510-5015 . ELEMENT;OIL FILTER 1
SERIAL: -980087
SERIAL_NO: ~980087
ICA: Y
REP_PNO: 65.05510-5021A
REP_QTY: 1
SC:
desc: . ELEMENT
LNKOP:
IP:
? 65.05510-5021A . ELEMENT;OIL FILTER 1
SERIAL: 980088-
SERIAL_NO: 980088~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . ELEMENT
LNKOP:
IP:
? 65.05503-0033B . HEAD;OIL FILTER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . CULASSE
LNKOP:
IP:
? 65.90310-0036 . PLUG;SCREW 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . VIS
LNKOP:
IP:
? 06.56190-0709 . RING;SEAL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BAGUE D'ETANCHEITE
LNKOP:
IP:
? 65.97601-0045 . SPRING;COMPRESS 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . RESSORT
LNKOP:
IP:
? 06.31641-0222 . BALL;STEEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BILLE
LNKOP:
IP:
? 65.90350-0005 . SCREW;PLUG PT 3/8 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . VIS
LNKOP:
IP:
? 06.01493-4206 BOLT M10X1.25X35 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 06.01493-4240 BOLT;HEX. M10X1.25X105 1
SERIAL: -970094
SERIAL_NO: ~970094
ICA: I
REP_PNO: 65.90001-0162
REP_QTY: 1
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 65.90001-0162 BOLT M10X1.25X105 1
SERIAL: 970095-
SERIAL_NO: 970095~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 06.01493-4214 BOLT M10X1.25X75 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 06.16731-2108 WASHER;SPRING 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? 06.15010-2312 WASHER;PLAIN 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? 65.05901-0004 GASKET 1
SERIAL_NO:
ICA: I
REP_PNO: 65.05901C0004
REP_QTY: 1
SC:
desc: JOINT
LNKOP:
IP:
? 65.05901C0004 GASKET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT
LNKOP:
IP:

Other: DOOSAN-DAEWOO / SOLAR 130LC-V - DIEU(E130LC-V) / OIL FILTER(008 : 008)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
