| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 2400-1947A | LUBRICATOR PIPING | A/R | SERIAL: 50491- SERIAL_NO: 50491~ ICA: REP_PNO: REP_QTY: SC: D desc: LUBRIFICATION LNKOP: IP: |
|||
| ? | 2182-1820 | PIPE | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUYAU LNKOP: IP: |
|||
| ? | 2181-2527 | TEE | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TE LNKOP: IP: |
|||
| ? | 2181-1925 | ELBOW | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COUDE LNKOP: IP: |
|||
| ? | 2124-1027D2 | CLIP;PIPE | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: ATTACHE LNKOP: IP: |
|||
| ? | S6710041 | NIPPLE;GREASE | 4 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: GRAISSEUR LNKOP: IP: |
|||
| ? | S0504353 | BOLT M6X1.0X10 | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON A 6 PANS LNKOP: IP: |
|||
| ? | 2181-1110D1 | ADAPTER PT1/4- PF1/4 | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RACCORD LNKOP: IP: |
|||
| ? | 2184-1061D191 | HOSE PF1/4-1350L | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUYAU FLEXIBLE LNKOP: IP: |
|||
| ? | S5102303 | WASHER;SPRING | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RONDELLE ELASTIQUE LNKOP: IP: |
