| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 65.01401-0224A | HOUSING;FLYWHEEL | 1 | SERIAL: -010730 SERIAL_NO: ~010730 ICA: I REP_PNO: 65.01401-0119 REP_QTY: 1 SC: desc: CARTER LNKOP: IP: |
|||
| ? | 65.01401-0119 | HOUSING;FLYWHEEL | 1 | SERIAL: 010731- SERIAL_NO: 010731~ ICA: REP_PNO: REP_QTY: SC: desc: CARTER LNKOP: IP: |
|||
| ? | 06.01494-4407 | BOLT;HEX. M14X1.5X40 | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON A 6 PANS LNKOP: IP: |
|||
| ? | 06.01494-4409 | BOLT;HEX. M14X1.5X50 | 6 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON A 6 PANS LNKOP: IP: |
|||
| ? | 06.16731-2110 | WASHER;SPRING | 8 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RONDELLE ELASTIQUE LNKOP: IP: |
|||
| ? | 06.11063-9217 | NUT M14X1.5 | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: ECROU LNKOP: IP: |
|||
| ? | 06.22022-3111 | PIN | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: GOUJON LNKOP: IP: |
|||
| ? | 65.96401-0007 | CAP;RUBBER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: CHAPEAU DE CAOUTCHOUC LNKOP: IP: |
|||
| ? | 65.01510-0101 | SEAL;OIL(REAR) | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT D'HUILE LNKOP: IP: |
|||
| ? | 65.01904-0021 | GASKET;FLY WHEEL HOUSING | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT DE CULASSE LNKOP: IP: |
