Содержание Other: DOOSAN-DAEWOO SOLAR 130LC-V - DIEU(E130LC-V)
BUCKET CYLINDER(4260 : 4260)
Номер на схеме Каталожный номер Название Количество Детали
? 2440-9233 BUCKET CYLINDER 1
SERIAL: 1-50150
SERIAL_NO: 1~50150
ICA: I
REP_PNO: 2440-9233A
REP_QTY: 1
SC:
desc: VERIN DE GODET
LNKOP:
IP:
? 2440-9233A BUCKET CYLINDER 1
SERIAL: 50151-50280
SERIAL_NO: 50151~50280
ICA: I
REP_PNO: 2440-9233B
REP_QTY: 1
SC:
desc: VERIN DE GODET
LNKOP:
IP:
? 2440-9233B BUCKET CYLINDER 1
SERIAL: 50281-50580
SERIAL_NO: 50281~50580
ICA: I
REP_PNO: 440-00398
REP_QTY: 1
SC:
desc: VERIN DE GODET
LNKOP:
IP:
? 440-00398 BUCKET CYLINDER 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VERIN DE GODET
LNKOP:
IP:
? 53U295-0 TUBE ASS'Y 1
SERIAL: 1-50280
SERIAL_NO: 1~50280
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU
LNKOP:
IP:
? 53U295-1 TUBE ASS'Y 1
SERIAL: 50281-50580
SERIAL_NO: 50281~50580
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU
LNKOP:
IP:
? 53U295-2 TUBE ASS'Y 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU
LNKOP:
IP:
? 53U301-0 BUSH STEEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? 53U302-0 ROD ASS'Y 1
SERIAL: 1-50280
SERIAL_NO: 1~50280
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TIGE
LNKOP:
IP:
? 53U302-1 ROD ASS'Y 1
SERIAL: 50281-50580
SERIAL_NO: 50281~50580
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TIGE
LNKOP:
IP:
? 53U302-5 ROD ASS'Y 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TIGE
LNKOP:
IP:
? 53B238-0 BUSH STEEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? 53U307-0 PISTON 1
SERIAL: 1-50580
SERIAL_NO: 1~50580
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PISTON
LNKOP:
IP:
? 53U307-2 PISTON 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PISTON
LNKOP:
IP:
? 00W239-0 RING;WEAR 2
SERIAL: 1-50280
SERIAL_NO: 1~50280
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE DE SOUTIEN
LNKOP:
IP:
? 00Z116-0 RING;WEAR 2
SERIAL: 50281-
SERIAL_NO: 50281~
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE DE SOUTIEN
LNKOP:
IP:
? 00R726-0 RING;SLYD 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: SEGMENT GLYD
LNKOP:
IP:
? E6490082 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 53U258-0 RING;BACK UP 1
SERIAL: 1-50580
SERIAL_NO: 1~50580
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE DE SOUTIEN
LNKOP:
IP:
? 53U258-1 RING;BACK UP 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE DE SOUTIEN
LNKOP:
IP:
? 53U308-0 RING;CUSHION 1
SERIAL: 1-50580
SERIAL_NO: 1~50580
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE
LNKOP:
IP:
? 53U368-0 RING;CUSHION 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE
LNKOP:
IP:
? 53U309-1 NUT;PISTON 1
SERIAL: 1-50580
SERIAL_NO: 1~50580
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? 53U309-2 NUT;PISTON 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? E1330534 SCREW;SET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? 53U306-0 ROD COVER 1
SERIAL: 1-50580
SERIAL_NO: 1~50580
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? 53U306-1 ROD COVER 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? E8412163 DU-BUSH 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUSSINET
LNKOP:
IP:
? 00M321-0 RING;RETAINING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: ARRET
LNKOP:
IP:
? E5500200 SEAL;BUFFER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT
LNKOP:
IP:
? E5302620 U-PACKING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT EN U
LNKOP:
IP:
? E6020200 WIPER;DUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: PARE-POUSSIERE
LNKOP:
IP:
? 00M323-0 RING;RETAINING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARRET
LNKOP:
IP:
? E6311481 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 53U259-0 RING;BACK UP 1
SERIAL: 1-50580
SERIAL_NO: 1~50580
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE DE SOUTIEN
LNKOP:
IP:
? 53U259-1 RING;BACK UP 1
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE DE SOUTIEN
LNKOP:
IP:
? E6311501 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? E0501839 BOLT;SOCKET HEX. 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? 03U522-3 PIPE ASS'Y-H 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU
LNKOP:
IP:
? E6300471 O-RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? E0500936 BOLT;SOCKET HEX. 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? E3110092 WASHER;SPRING 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE GROWER
LNKOP:
IP:
? 53U310-1 PIPE ASS'Y-R 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CONDUITES
LNKOP:
IP:
? 53U256-0 PIPE BAND ASS'Y 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE DE FIXATION
LNKOP:
IP:
? 04B320-0 BAND PIPE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CONDUITES DE FIXATION
LNKOP:
IP:
? E0020682 BOLT;HEX. 4
SERIAL: 1-50580
SERIAL_NO: 1~50580
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? E0020673 BOLT;HEX. 4
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? E3110102 WASHER;SPRING 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE GROWER
LNKOP:
IP:
? 00C266-0 CLAMP;PIPE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: FIXATION DE TUYAU
LNKOP:
IP:
? E0020712 BOLT;HEX. 4
SERIAL: 1-50580
SERIAL_NO: 1~50580
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? E0020713 BOLT;HEX. 4
SERIAL: 50581-
SERIAL_NO: 50581~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? E8841022 NIPPLE;GREASE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GRAISSEUR
LNKOP:
IP:
? 2440-9233KT SEAL KIT;BUCKET CYL. 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: S
desc: KIT DE JOINT
LNKOP:
IP:
