Содержание Other: DOOSAN-DAEWOO SOLAR 130LC-V - DIEU(E130LC-V)
BOOM CYLINDER-L.H (3)(4232 : 4232)
Номер на схеме Каталожный номер Название Количество Детали
? 440-00115A BOOM CYLINDER-L.H 1
SERIAL: 50521-50560
SERIAL_NO: 50521~50560
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VERIN DE FLECH
LNKOP:
IP:
? 440-00115A BOOM CYLINDER-L.H 1
SERIAL: 50571-
SERIAL_NO: 50571~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VERIN DE FLECH
LNKOP:
IP:
? 53B370-6 TUBE ASS'Y 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU
LNKOP:
IP:
? 00T152-0 BUSH;STEEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? 53B376-3 ROD ASS'Y 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TIGE
LNKOP:
IP:
? 53B339-0 BUSH;STEEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? 53B382-2 COVER;ROD 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? E8412169 DU-BUSH 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUSSINET
LNKOP:
IP:
? 00M322-0 RING;RETAINING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARRET
LNKOP:
IP:
? E5500220 SEAL;BUFFER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT
LNKOP:
IP:
? E5302740 U-PACKING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT EN U
LNKOP:
IP:
? E6020220 WIPER;DUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: PARE-POUSSIERE
LNKOP:
IP:
? 00M312-0 RING;RETAINING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARRET
LNKOP:
IP:
? E6311501 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 53B318-0 RING;BACK UP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: ANNEAU DE SOUTIEN
LNKOP:
IP:
? E6311521 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 00C302-0 RING;CUSHION 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE
LNKOP:
IP:
? 53B379-2 PISTON 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PISTON
LNKOP:
IP:
? E5130200 SEAL;SLIPPER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT
LNKOP:
IP:
? 00Z117-0 RING;WEAR 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE DE SOUTIEN
LNKOP:
IP:
? 00R095-0 RING;SLYD 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE
LNKOP:
IP:
? E6490085 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 53B317-0 RING;BACK UP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: ANNEAU DE SOUTIEN
LNKOP:
IP:
? 53B381-1 NUT;PISTON 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? E1330544 SCREW;SET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? E0501839 BOLT;SOCKET 10
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? 53B385-0 PIPE BAND ASS'Y 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE DE FIXATION
LNKOP:
IP:
? 03U345-0 BAND;PIPE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ATTACHE
LNKOP:
IP:
? E3110102 WASHER;SPRING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? E0020673 BOLT;HEX. 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 53B606-1 PIPE ASS'Y-H 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CONDUITES
LNKOP:
IP:
? E3110102 WASHER;SPRING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? E0020633 BOLT;HEX. 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 53B384-0 PIPE ASS'Y-R 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CONDUITES
LNKOP:
IP:
? E6300471 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? E3110092 WASHER;SPRING 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? E0500936 BOLT;SOCKET 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS CREUX
LNKOP:
IP:
? E8841022 NIPPLE;GREASE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GRAISSEUR
LNKOP:
IP:
? 2440-9230KT SEAL KIT;BOOM CYL. 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: S
desc: KIT DE JOINT
LNKOP:
IP:
