Содержание Other: DOOSAN-DAEWOO SOLAR 130LC-V - DIEU(E130LC-V)
TRACK SPRING(2)(2131 : 2131)
Номер на схеме Каталожный номер Название Количество Детали
? 2274-1034 TRACK SPRING ASS'Y 2
SERIAL: 50151-50210
SERIAL_NO: 50151~50210
ICA: I
REP_PNO: 2274-1034A
REP_QTY: 2
SC:
desc: ENSEMBLE TENDEUR DE CHENILLE
LNKOP:
IP:
? 2274-1034A TRACK SPRING ASS'Y 2
SERIAL: 50211-50370
SERIAL_NO: 50211~50370
ICA: I
REP_PNO: 2274-1034C
REP_QTY: 2
SC:
desc: ENSEMBLE TENDEUR DE CHENILLE
LNKOP:
IP:
? 2274-1034C TRACK SPRING ASS'Y 2
SERIAL: 50371-
SERIAL_NO: 50371~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE TENDEUR DE CHENILLE
LNKOP:
IP:
? 2157-1016 YOKE 1
SERIAL: 50151-50370
SERIAL_NO: 50151~50370
ICA: I
REP_PNO: 2157-1016A
REP_QTY: 1
SC:
desc: ETRIER
LNKOP:
IP:
? 2157-1016A YOKE 1
SERIAL: 50371-
SERIAL_NO: 50371~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ETRIER
LNKOP:
IP:
? 2444-1012A ROD;PISTON 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TIGE DE PISTON
LNKOP:
IP:
? S0712251 BOLT M10X1.25 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S5102602 WASHER;SPRING M10 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE GROWER
LNKOP:
IP:
? S8010551 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 2181-1546 FLANGE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BRIDE
LNKOP:
IP:
? 2440-1117 CYLINDER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CYLINDRE
LNKOP:
IP:
? 2129-1474 SPRING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESSORT
LNKOP:
IP:
? 2411-1001 RING;PISTON 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: SEGMENT DE PISTON
LNKOP:
IP:
? 2180-9001 PACKING;U-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT
LNKOP:
IP:
? S6500400 RING;RETAINING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE
LNKOP:
IP:
? 2444-1013B ROD 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TIGE
LNKOP:
IP:
? 2180-1026D21 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? 2197-2119 BRACKET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT
LNKOP:
IP:
? 2110-1114 BUSHING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? 2120-1105 BOLT M10X1.25 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 2121-1054 NUT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? 2420-1035A VALVE ASS'Y 1
SERIAL: 50151-50370
SERIAL_NO: 50151~50370
ICA: I
REP_PNO: 2420-1242A
REP_QTY: 1
SC:
desc: ENSEMBLE CLAPET
LNKOP:
IP:
? 2420-1242A VALVE ASS'Y 1
SERIAL: 50371-
SERIAL_NO: 50371~
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE CLAPET
LNKOP:
IP:
? S0721551 BOLT M16X1.5X45 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S5102902 WASHER;SPRING M16 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE GROWER
LNKOP:
IP:
? 2274-1008BKT SEAL KIT;TRACK SPRING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: KIT D'ETANCHEITE
LNKOP:
IP:

Other: DOOSAN-DAEWOO / SOLAR 130LC-V - DIEU(E130LC-V) / TRACK SPRING(2)(2131 : 2131)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
