Содержание Other: DOOSAN-DAEWOO 460(460)
OIL COOLER PIPING(3130 : 3130)
Номер на схеме Каталожный номер Название Количество Детали
? K1021558 HYD PIPING A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: TUYAUTERIE DE L'HYDRAULIQUE
LNKOP:
IP:
? K1022640 VALVE;CHECK 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VANNE DE CONTROLE
LNKOP:
IP:
? S0508863 BOLT 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? K1023146 WASHER;HARDENED 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? K1022540 SWITCH;PRESSURE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: MANOSTAT
LNKOP:
IP:
? K1023087 TEE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TE
LNKOP:
IP:
? K1023063 ELBOW 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUDE
LNKOP:
IP:
? K1023073 ELBOW 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUDE
LNKOP:
IP:
? S0508663 BOLT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? K1022549 TEE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TE
LNKOP:
IP:
? K1023075 ELBOW 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUDE
LNKOP:
IP:
? DS2472001 ELBOW 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUDE
LNKOP:
IP:
? K1023070 ELBOW 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUDE
LNKOP:
IP:
? DS2012147 HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? DS2012106 HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? DS2013823 HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? DS2013123 HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? DS2013157 HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? DS2013475 HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? K1023094 HOSE;BULK 206
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: CM
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? S8450035 CLAMP;HOSE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
IP:
? S8030101 O-RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? S8040101 O-RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? S8030121 O-RING 10
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? S8040121 O-RING 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? S8040161 O-RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? K1022470 ELBOW 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUDE
LNKOP:
IP:
? K1022545 ADAPTER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RACCORD ADAPTATEUR
LNKOP:
IP:
? K1022550 PROTECTOR;HOSE 110
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: CM
desc: PROTECTEUR
LNKOP:
IP:
? K1019823 CLAMP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
IP:
? K1021844 PLUG 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? K1023054 CLIP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE D'ARRET
LNKOP:
IP:
? DS2028009 HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? S8450023 CLAMP;HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
IP:

Other: DOOSAN-DAEWOO / 460(460) / OIL COOLER PIPING(3130 : 3130)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
