| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 65.06500-6178B | WATER PUMP ASS'Y | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: ENSEMBLE POMPE A EAU LNKOP: IP: |
|||
| ? | 65.06501-0099A | . HOUSING;WATER PUMP | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: . LOGEMENT LNKOP: IP: |
|||
| ? | 65.06520-6007 | . SEAL;MECHANICAL | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . JOINT LNKOP: IP: |
|||
| ? | 65.93410-0027 | . BEARING | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . ROULEMENT LNKOP: IP: |
|||
| ? | 06.29020-0132 | . SNAP RING 55X2 | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . BAGUE ELASTIQUE LNKOP: IP: |
|||
| ? | 65.06504-0033 | . HUB;V-BELT PULLEY | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . MOYEU LNKOP: IP: |
|||
| ? | 65.06506-0029A | . IMPELLER;WATER PUMP | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . TURBINE LNKOP: IP: |
|||
| ? | 65.06503-0113 | PULLEY;V-BELT | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: POULIE LNKOP: IP: |
|||
| ? | 65.06901-0042 | GASKET;WATER PUMP | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT LNKOP: IP: |
|||
| ? | 06.01913-3120 | BOLT ASS'Y M8X45 | 5 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON LNKOP: IP: |
|||
| ? | 06.01913-3121 | BOLT ASS'Y M8X50 | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON LNKOP: IP: |
|||
| ? | 65.06301-0258A | PIPE;COOLING WATER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUYAU LNKOP: IP: |
|||
| ? | 65.06903-0029 | GASKET;WATER PIPE | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT LNKOP: IP: |
|||
| ? | 06.01913-3117 | BOLT ASS'Y M8X30 | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON LNKOP: IP: |
